RABBETED HALF-BLIND DOVETAILS
46
Chapter 11 Super Jig-12-18-24 User Guide
11-5 Stick the block
to the jig face with double-sided tape,
making sure it touches the side stop.
�
11-6 The drawer side will now be stepped in from the side stop
by the width of the rabbet, bringing the sockets in line with
the pins.
11-7 Make sure you select a dovetail bit that has a working depth
of cut less than the rabbet height. Otherwise, you will rout into the
rabbet.
11-8 It is difficult to clean up the drawer sides and front corner
after assembling a rabbeted drawer, so make sure the fit is flush
before you complete the drawers See 9-28 to 9-30.
■
