3 VALVES
3.1 Valve overview
The field sprayer is fitted with manually operated valves which cover all required
work functions depending on the switching position.
1. Filling valve(s)
2. Selection valve
3. Valve for the internal cleaning
4. Distribution valve
5. Induction valve
6. Rinsing valve
7. Valve block of the chemical inductor
8. Valve for the agitator nozzle
9. Valve for the boundary wetting
10. Valve for the canister rinsing
11. Valve for the outside cleaning
1
2
5
7
8 9 10
11
1
2
3
4
6
