- Put selection valve (6) in the “main tank”
position
- Only then put the filling valve or filling
valves (5) into the “suction from selection
valve” position when the pump is
running.
- Remove filling hose (2) and replace the
sealing cap (1).
IMPORTANT!
In combination with a chemical inductor, pesticides can already be inducted
during the filling process after the main tank has already been filled with 100 litres
of clean water. Empty canisters should be rinsed and the inside of the chemical
inductor, the agitation nozzle and the canister rinsing nozzle should be cleaned
during the filling process. The externally drawn in clean water can be used for
cleaning purposes during the filling of the main tank. The limited capacity of the
clean water tank can then mainly be used for the internal cleaning of the main
tank, the outside cleaning and the system cleaning of the field sprayer.
4
6
5
6
5
