27
DC-3100 /DC3100N / DC-4600 PARTS LIST
Oct11
Pos. Part nos. Description Qty.
Pos. Part nos. Description Qty.
L045-010 DC-3100 airless piston pump on stand
L045-011 DC-3100N airless piston pump on cart
1 L045-400 Decal, DC3100/N front cover 1
L045-760 Decal, DC4600 front cover 1
2 L045-401 Front cover 1
3 L045-402 Screw 8
4 L045-403 Second stage gear 1
5 L045-404 Thrust washer 1
6 L045-405 Crankshaft/gear assembly 1
7 L045-406 Motor assembly (#8,9,14-17) 1
8 L013-512 Tie wrap 4
9 L045-408 Capacitor 1
10 L002-818 Bolt, 1/4 x 1" NC
14 L045-410 Fan 1
15 L045-755 Fan screw 1
16 L045-411 Fan shroud (half) 2
17 L045-525 Screw 2
18 L045-412 Motor cover 1
19 L045-413 Screw 4
22 L045-414 Slider assembly (for piston w/pin) 1
L045-319 Slider assembly (for slotted piston) 1
23 L045-806 Connecting pin
(for piston with hole)
1
24 L045-807 Retaining ring (for slider w/pin only) 1
25 L045-415 Retainer nut 1
•26 L045-416 Piston guide 1
•27 L045-417 Upper packing 1
•28 L045-418 Spacer 1
29 L045-419 Filter housing 1
30 L032-516 Filter 1
31 L032-514 Filter seal 1
32 L045-422 Pump manifold, DC31 1
L045-493 Pump manifold, DC46 1
33 L045-423 Bolt 2
34 L035-714 Return hose fittiing, 1/8" 1
35 L045-425 Outlet fitting, 1/4" 1
36 L045-862 PRIME/SPRAY valve assembly 1
•41 L045-426 Lower packing set (pack of 2) 1
42 L045-427 Piston rod, with pin-hole 1
L045-316 Piston rod, slotted (DC3100N) 1
43 L045-567 Shaft valve cage (plastic-older) 1
• L045-317 Shaft valve cage
(metal, must use seal)
1
•43a L045-318 Seal, shaft valve (for metal cage only) 1
•44 L060-519 Shaft valve ball 1
45 L060-520 Shaft valve seat 1
46 L045-428 Shaft valve retainer 1
47 L045-429 Piston bushing 1
•48 L045-430 Nylon washer 1
49 L045-431 Inlet valve cage 1
•50 L045-432 Inlet valve ball 1
51 L045-433 Inlet valve seat 1
•52 L045-434 O-ring, Teflon 1
53 L045-435 Inlet valve housing (stand) 1
L045-436 Inlet valve housing (cart) 1
54 L045-437 Suction set assembly 1
55 L045-752 Return hose clamp 1
56 L045-438 Return hose 1
57 L045-592 Retaining ring 1
58 L045-584 O-ring 2
59 L013-512 Tie wrap 2
61 L045-581 Hose clip 1
62 L045-579 Inlet screen, 16 mesh 1
L045-593 Inlet screen, 12 mesh opt
67 L045-441 Screw 1
68 L045-442 Pressure control knob 1
69 L045-443 Knob housing 1
70 L045-536 Knob spring 1
71 L045-534 Washer 1
72 L045-444 Plunger 1
73 L045-712 ON/OFF switch 1
74 L045-445 Circuit breaker (DC31) 1
75 L045-446 Microswitch insulator 1
76 L045-725 Microswitch 1
77 L045-559 Screw 2
78 L045-447 Screw 3
79 L045-448 Flat washer 3
80 L045-521 Relay, 120V
(DC3100) DC3100N is below
1
81 L045-320
Motor control ass'y (incl. #80, 82) DC3100N
1
L045-449 Heat sink ass'y (incl. #81,82) DC31 1
L045-492 Heat sink ass'y (incl. #81,82) DC46 1
82 L045-450 Port plug 1
84 L045-451 Transducer assembly (includes o-ring) 1
85 L045-452 Ground screw 1
86 L045-453 Power cord assembly (stand) 1
L045-454 Power cord assembly (cart) 1
89 L045-455 Nut 1
90 L045-456 Right leg assembly (incl. #94,89,96-99)1
91 L045-457 Left leg assembly (incl. #92,94,95) 1
92 L045-589 Cord wrap 1
93 L045-458 Screw 4
94 L045-459 Plug 4
95 L045-460 Screw 2
96 L045-461 Clip assembly 1
97 L045-462 Screw 1
98 L045-588 Drip cup 1
99 L045-463 Screw 1
100 L045-464 Handle assembly (incl. #) 1
101 L045-744 Handle sleeve 2
102 L045-743 Snap button 2
103 L045-745 Handle washer 2
104 L045-742 Pin 2
105 L045-885 Washer 6
106 L045-746 Screw 4
107 L045-482 Cord wrap 2
108 L045-483 Screw 4
109 L045-885 Washer 6
110 L045-485 Cart frame, DC46 (incl 114,115) 1
111 L045-749 Wheel 2
112 L056-583 Cap 2
113 L056-582 Spacer 4
114 L045-478 Plug, cart frame 2
115 L045-481 Plug, cart frame 2
116 L045-484 Bolt, DC46 cart 4
119 L045-883 Hose clip (cart only) 1
120 L045-465 Pail hook (DC46 cart only) 1
121 L045-466 Washer (cart only) 2
122 L045-467 Screw (cart only) 2
123 L045-468 Siphon tube (cart only) 1
124 L045-469 Return hose (cart only) 1
125 L045-860 Inlet screen (cart only) 1
126 L045-486 Motor fan, DC46 1
127 L045-487 Motor, DC46 w/front end bell 1
128 L045-488 Cover, electronic 1
129 L045-489 Electronic control assembly 1
130 L045-490 Fan shroud 1
131 L045-491 Motor, DC46 w/end bell & electronics 1
132 L045-494 Seal, DC46 filter cap 1
133 L045-495 Spring, DC46 filter 1
134 L045-496 Adapter, DC46 filter 1
135 L045-497 Spring, DC46 filter 1
136 L045-498 Filter, DC46 1
137 L045-499 Filter housing, DC46 1
138 L045-311 Cart frame, DC31 1
139 L045-312 Plug, DC31 4
Pump packing kit:
•140 L045-470 Packing kit (items " • ") (DC3100, DC3100N
& DC4600)
L045-471 Lower seal insertion tool
Accessories:
L034-125 Packing lubricating oil, squeeze bottle
L050-621 Owner’s manual
L045-472 Motor Brush Kit, DC31
L045-473 Fluid sect compl. DC31stand (#25-32,34-53)
L045-474 Fluid sect compl. DC46cart (#25-32,34-53)
L045-479 Lubriplate, 5 ounce
