INTRODUCTION:
We appreciate your decision to purchase a Lemmer professional quality
professional paint spraying system and believe you will find it to be the
best sprayer you ever owned.
Your Lemmer airless paint machine is capable of spraying a wide variety
of latex, oil-based and alkyd paints, as well as stains, preservatives and
other architectural coatings. The material you are spraying will have a
direct effect on the amount of pressure required for the optimum pattern
and coverage to be obtained. We recommend that before actually
beginning your job, you carefully read this manual and practice with the
sprayer until you feel comfortable using it.
These Lemmer sprayers are powerful and versatile enough to be used
with a variety of accessories (extra lenghts of hose, extensions,
pressure feed rollers, etc. as shown later in this manual) to make them
even more versatile systems. Ask your supplier about the recommended
accessories for your particular job.
PUMP TYPE:
The Lemmer DC units use a double acting piston pump, with stationary
packings. This gives good service life and is a simple to maintain
system. The valves are stainless steel balls with tungsten carbide seats,
giving very good reliability.
Industrial grade DC motors are used in conjunction with reliable
pressure control sytems.
PRODUCT SPECIFICATIONS
ADVANTAGES OF THESE SYSTEMS ARE:
• Pump stops working when you do. Minimizes wear.
• Accurate spray pattern with minimal overspray.
• Minimal or no thinning of paint products.
• Pumps straight out of original paint container.
• Variable pressure from 0 to 3000 PSI.
• Various nozzles are available for slow to fast spraying.
• Light weight, compact and portable.
• Quiet running and low power consumption.
• Steady spraying pressure - minimal fan fluctuations.
• Compact paint pump - quick cleaning, less parts to wear.
TECHNICAL SPECIFICATIONS
DC-1600 DC-2000 DC-3100 DC-7700
Weight: 22 lbs (10 kg) w/ght 31 lbs (14 kg) 30 lbs (14 kg) 95 lbs
Capacity, volume @ 2000 psi: .25 gpm .39 gpm .47 gpm 1.1 gpm
Maximum tip size, 1 gun: .017 (.015 installed) 019 (.017 installed) .021 (.019 installed) .031 (.029 installed)
Maximum tip size, 2 gun: .015 (.013 installed) .021 (.019 installed)
Motor: 1/2 hp dc industrial 5/8 hp dc industrial 3/4 hp dc industrial 1.6 hp PMDC industrial
Power requirements, 110V: 6.5A,115VAC,60HZ 6.0A,115VAC,60HZ 6.5A,115VAC,60HZ 12.7A,115VAC,60HZ
Spraying pressure: 0 - 2800 psi 0 - 2800 psi 0 - 3000 psi 0 - 3000 psi
Maximum hose length: 200 feet (61meters) 300 feet (91meters) 300 feet (91meters) 300 feet (91meters)
Maximum power cord: 300 feet (14-16 guage) 300 feet (14-16 guage) 300 feet (14-16 guage) 200 feet (12-14 guage)
Paint inlet: spl metric spl metric swivel 1" npt(f)
Paint outlet: 1/4" npt(m) 1/4" npt(m) 1/4" npt(m) 1/4" npt(m)
Wetted parts: Al,Cu,SS,Tc,Tef,Lea,Brass,Nylon Al,Cu,SS,Tc,Tef,Lea,Brass,Nylon Al,Cu,SS,Tc,Tef,Lea,Brass,Nylon Al,Cu,SS,Tc,Tef,Lea,Brass,Nylon,Chrome,Zinc
Capability: All conventional coatings, ie: latex, stain, lacquer, varnish, ink, primer, preservatives and many other architectural coatings, and with the
DC-4600 and DC-7700 also heavier coatings such as block filler and some elastomerics and glues.
IMPORTANT NOTICES:
Due to the nature of operation of this unit, even though the motor cuts off, or appears to have cut off, it may re-start at any time. Even
once the switch has been turned off, there will likely be pressure remaining in the system. Do not service the unit unless it has been
turned off, unplugged and the pressure has been relieved. Pressure is relieved by turning the prime knob counter clockwise and double
checking by triggering the gun.
DO NOT USE STEEL BRAID paint spray hose! The DC-1600/2000/3100/7700 can only be used with fibre braid hose.
