TIP SELECTION
TIP SELECTION:
A standard size .017 tip will give good performance in latex or oil base
materials of moderate viscosities.
The following chart gives a basic idea of what tips the Lemmer sprayers
can handle performance wise and what tip is appropriate for which
material. Gun filter sizing is also included in the chart for handy refer-
ence.
For a much more detailed look at tip sizes, please consult the detailed
tip chart on page 10.
Tip size Paint type Filter size
.011 Lacquers, industrial enamel, red
very thin paints.
.013 Oil stains, pigmented lacquers, yellow
red oxide primer.
.015 Normal application of latex, oil base, yellow
stains and , solid color oil stains.
.017 Fast application of latex paints white
and stains, oil base paints.
.019 Heavier body latex paints. white
.021 Fast application of heavier latex white
paint, smooth block filter when
properly thinned.
.021 Maximum tip on DC-3100 not req’d
.025 Maximum tip on DC-4600 not req’d
.031 Maximum tip on DC-7700 not req’d
.045 Maximum tip on HP-9500 not req’d
The maximum tip for a pump is the largest tip that will deliver a proper
pressure for spraying without overworking or overloading. When a tip is
used for some period of time, it can wear beyond the maximum for the
pump, which will cause low pressure and poor spray pattern.
Stains and thick latex products often cause the most rapid wear of the
tip, while clear lacquers and varnishes cause the least wear. Thus tip life
can vary from as little as 50 gallons to as much as 200 or more,
depending on the product being sprayed and the pressure used.
Filters for the gun are picked not because of the type of paint being
used, but to protect a given size of tip. You pick the tip for the type of
paint and job being done and then choose the filter to protect that tip.
The chart on page 10 gives much more detail about tip and filter
choices.
THE TWO MOST IMPORTANT THINGS TO REMEMBER ABOUT
TIPS.....
1) Low pressure means longer life, for tips and the pump. Less
overspray too!
2) Worn tips waste paint and overwork the pump, wearing it out
quickly.
Order Number Orifice Fan Fan Flow Tip
Zip Tip BB Tip at 1' Angle Ltr/min mark
L043-091 0.009 2" 10 DEG. 0.26 109
L043-092 L038-092 0.009 4" 20 DEG. 0.26 209
L043-093 L038-093 0.009 6" 30 DEG. 0.26 309
L043-094 L038-094 0.009 8" 40 DEG. 0.26 409
L043-095 L038-095* 0.009 10" 50 DEG. 0.26 509
L043-096 L038-096* 0.009 12" 60 DEG. 0.26 609
L043-111 L038-111 0.011 2" 10 DEG. 0.4 111
L043-112 L038-112 0.011 4" 20 DEG. 0.4 211
L043-113 L038-113 0.011 6" 30 DEG. 0.4 311
L043-114 L038-114 0.011 8" 40 DEG. 0.4 411
L043-115 L038-115 0.011 10" 50 DEG. 0.4 511
L043-116 L038-116 0.011 12" 60 DEG. 0.4 611
L043-117 0.011 14" 70 DEG. 0.4 711
L043-131 L038-131 0.013 2" 10 DEG. 0.6 113
L043-132 L038-132 0.013 4" 20 DEG. 0.6 213
L043-133 L038-133 0.013 6" 30 DEG. 0.6 313
L043-134 L038-134 0.013 8" 40 DEG. 0.6 413
L043-135 L038-135 0.013 10" 50 DEG. 0.6 513
L043-136 L038-136 0.013 12" 60 DEG. 0.6 613
L043-137 0.013 14" 70 DEG. 0.6 713
L043-138 0.013 16" 80 DEG. 0.6 813
L043-151 0.015 2" 10 DEG. 0.8 115
L043-152 L038-152 0.015 4" 20 DEG. 0.8 215
L043-153 L038-153 0.015 6" 30 DEG. 0.8 315
L043-154 L038-154 0.015 8" 40 DEG. 0.8 415
L043-155 L038-155 0.015 10" 50 DEG. 0.8 515
L043-156 L038-156 0.015 12" 60 DEG. 0.8 615
L043-157 0.015 14" 70 DEG. 0.8 715
L043-171 0.017 2" 10 DEG. 1 117
L043-172 L038-172 0.017 4" 20 DEG. 1 217
L043-173 L038-173 0.017 6" 30 DEG. 1 317
L043-174 L038-174 0.017 8" 40 DEG. 1 417
L043-175 L038-175 0.017 10" 50 DEG. 1 517
L043-176 L038-176 0.017 12" 60 DEG. 1 617
L043-177 0.017 14" 70 DEG. 1 717
L043-178 0.017 16" 80 DEG. 1 817
L043-192 0.019 4" 20 DEG. 1.3 219
L043-193 L038-193 0.019 6" 30 DEG. 1.3 319
L043-194 L038-194 0.019 8" 40 DEG. 1.3 419
L043-195 L038-195 0.019 10" 50 DEG. 1.3 519
L043-196 L038-196 0.019 12" 60 DEG. 1.3 619
L043-197 0.019 14" 70 DEG. 1.3 719
L043-198 0.019 16" 80 DEG. 1.3 819
L043-213 L038-213 0.021 6" 30 DEG. 1.6 321
L043-214 L038-214 0.021 8" 40 DEG. 1.6 421
L043-215 L038-215 0.021 10" 50 DEG. 1.6 521
L043-216 L038-216 0.021 12" 60 DEG. 1.6 621
L043-217 0.021 14" 70 DEG. 1.6 721
L043-218 0.021 16" 80 DEG. 1.6 821
L043-219 0.021 18" 90 DEG. 1.6 921
L043-234 L038-234 0.023 8" 40 DEG. 1.9 423
L043-235 L038-235 0.023 10" 50 DEG. 1.9 523
L043-236 0.023 12" 60 DEG. 1.9 623
L043-237 0.023 14" 70 DEG. 1.9 723
L043-238 0.023 16" 80 DEG. 1.9 823
L043-239 0.023 18" 90 DEG. 1.9 923
L043-254 0.025 8" 40 DEG. 2.3 425
L043-255 L038-255 0.025 10" 50 DEG. 2.3 525
L043-256 0.025 12" 60 DEG. 2.3 625
L043-257 0.025 14" 70 DEG. 2.3 725
L043-258 0.025 16" 80 DEG. 2.3 825
L043-259 0.025 18" 90 DEG. 2.3 925
L043-274 0.027 8" 40 DEG. 2.7 427
L043-275 L038-275 0.027 10" 50 DEG. 2.7 527
L043-276 0.027 12" 60 DEG. 2.7 627
L043-277 0.027 14" 70 DEG. 2.7 727
L043-278 0.027 16" 80 DEG. 2.7 827
L043-279 0.027 18" 90 DEG. 2.7 927
L043-294 0.029 8" 40 DEG. 3.1 429
L043-295 L038-295 0.029 10" 50 DEG. 3.1 529
L043-296 0.029 12" 60 DEG. 3.1 629
L043-297 0.029 14" 70 DEG. 3.1 729
L043-298 0.029 16" 80 DEG. 3.1 829
L043-299 0.029 18" 90 DEG. 3.1 929
L043-313 0.031 6" 30 DEG. 3.5 331
L043-314 0.031 8" 40 DEG. 3.5 431
L043-315 L038-315 0.031 10" 50 DEG. 3.5 531
L043-316 0.031 12" 60 DEG. 3.5 631
L043-317 0.031 14" 70 DEG. 3.5 731
L043-318 0.031 16" 80 DEG. 3.5 831
N/A L038-355 0.035 10" 50 DEG. 3.8 535
* LTD - Limited supply, special order when stocks are low.
Maximum volume discount allowed is 5+.
