Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
Page 48 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Unit 2170 Cust.Relay 2171 BM.NO7 R/W *
0=Not Set,
1=Alarm,
2=Fault,
3=Alarm C1,
4=Alarm C2,
5=Alarm Cond,
6=Alarm Pump Evap,
7=Alarm Flow Evap,
8=Enable,
9=Avaible,
10=Run,
11=Run 100%,
12=Cooling Mode,
13=Heating Mode,
14=Dead Zone Mode,
15=Zone 0,
16=Zone 1,
17=Zone 2,
18=Zone 3,
19=Zone 4,
20=Zone 5,
21=Zone 6,
22=Mode A,
23=Mode B,
24=Mode C,
25=Mode D,
26=Mode BMS,
27=Elec.Heater 1,
28=Elec.Heater 2,
29=Elec.Heater 3,
30=Elec.Heater 4,
31=Free BM.NO7,
32=Free BE.NO1,
33=Free BE.NO2,
34=Free BE.NO3,
35=Free BE.NO4,
36=Not Used,
37=Not Used,
38=Not Used,
39=Not Used,
40=Freecooling,
41=NSR 1, 42=NSR 2,
43=NSR 3, 44=NSR 4,
45=NSR 5.
Configuration of the free output
BM.NO7
User Unit Cust.Relay 2172 BE.NO1 R/W * * * *
Configuration of the free output
BE.NO1
User Unit Cust.Relay 2173 BE.NO2 R/W * * * *
Configuration of the free output
BE.NO2
User Unit Cust.Relay 2174 BE.NO3 R/W * * * *
Configuration of the free
output BE.NO3
User Unit Cust.Relay 2175 BE.NO4 R/W * * * *
Configuration of the free
output BE.NO4
