Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
MUL41E-0610/06-2011 Page 49
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Unit 2180 Cust.Switch 2181 BM.Id4 R/W *
0=Not Set,
1=On/Off,
2=Reset Alarm
3=Swap 2° SP,
4=Cooling,
5=Heating,
6=Dead Zone,
7=Delay Defrost,
8=Disable C1,
9=Disable C2,
10=Disable C1Cp1,
11=Disable C1Cp2,
12=Disable C1Cp3,
13=Disable C2Cp1,
14=Disable C2Cp2,
15=Disable C2Cp3,
16=Mode A,
17=Mode B,
18=Mode C,
19=Mode D,
20=Mode BMS,
21=Heater Elec.,
22=Free BM.Id4,
23=Free BM.Id7,
24=Free BE.Id1,
25=Free BE.Id2,
26=Free BE.Id3,
27=Free BE.Id4,
28=Not Used,
29=Not Used,
30=Not Used,
31=Not Used,
32=Not Used,
33=Freecooling,
34=Corrector FP,
35=NSR 1, 36=NSR 2,
37=NSR 3, 38=NSR 4,
39=NSR 5, 40=NSR 6.
Configuration of the free
input BM.Id4
User Unit Cust.Switch 2182 BM.Id7 R/W * * * *
Configuration of the free
input BM.Id7
User Unit Cust.Switch 2183 BE.Id1 R/W * * * *
Configuration of the free
input BE.Id1
User Unit Cust.Switch 2184 BE.Id2 R/W * * * *
Configuration of the free
input BE.Id2
User Unit Cust.Switch 2185 BE.Id3 R/W * * * *
Configuration of the free input
BE.Id3
User Unit Cust.Switch 2186 BE.Id4 R/W * * * *
Configuration of the free input
BE.Id4
User Unit 2190 Cust.Signal 2191 BE.B1 R/W *
0=Not Set,
1=Water Sp,
2=Offset Sp,
3=Free BE.B1,
4=Free BE.B2,
5=Free BE.B3,
6=Free BE.B4,
7=Discharge 1,
8=Discharge 2,
9=Discharge 3,
10=Discharge 4,
11=Condensor Inlet,
12=Condensor Outlet,
13=Freecooling Inlet,
14=Recovery Inlet,
15=Recovery Outlet,
16=NSR 1, 17=NSR 2,
18=NSR 3, 19=NSR 4.
Configuration of the free input
BE.B1
User Unit Cust.Signal 2192 BE.B2 R/W * * * *
Configuration of the free input
BE.B2
User Unit Cust.Signal 2193 BE.B3 R/W * * * *
Configuration of the free input
BE.B3
User Unit Cust.Signal 2194 BE.B4 R/W * * * *
Configuration of the free input
BE.B4
