Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User 2200 Water 2210 General 2211 Inlet R °C -50,0 * 105,0 Evaporator inlet probe T°
User Water General 2212 Inlet Ref R °C -50,0 * 105,0 Evaporator inlet reference T°
User Water General 2213 Outlet R °C -50,0 * 105,0 Evaporator outlet probe T°
User Water General 2214 Outlet Ref R °C -50,0 * 105,0 Evaporator outlet reference T°
User Water General 2215 Delta T° R °C -50,0 * 105,0
Evaporator delta T° (Inlet-
Outlet)
User Water General 2216 Setpoint R °C -50,0 * 105,0 Evaporator set point
User Water General 2217 Capacity R % -50,0 * 105,0 Evaporator capacity
User Water General 2218 Flow R * 0 * 1 Evaporator flow switch
User Water 2220 Changeover 2221 Status R * * * * Changeover status
User Water Changeover 2222 Outside R °C -50,0 * 105,0 Outside air probe T°
User Water Changeover 2223 Outside Ref R °C -50,0 * 105,0 Outside air reference T°
User Water Changeover 2224 Mode R/W *
0=Not Used,
1=Cool,
2=Heat,
3=Auto,
4=Dead zone.
Changeover mode
User Water 2230 Cooling 2231 Status R * * * * Evaporator status
User Water Cooling 2232 Inlet R °C -50,0 * 105,0 Evaporator inlet reference T°
User Water Cooling 2233 Outlet R °C -50,0 * 105,0 Evaporator outlet reference T°
User Water Cooling 2234 Setpoint R °C -50,0 * 105,0 Evaporator set point
User Water Cooling 2235 Capacity R °C 0,0 * 100,0 Evaporator cooling capacity
User Water Cooling 2236 Air 1 R/W/Z °C -11,0 22,0 50,0 Outside air set point X1 in cool
User Water Cooling 2237 Air 2 R/W/Z °C -11,0 30,0 50,0 Outside air set point X2 in cool
User Water Cooling 2238 Water 1 R/W/Z °C 19,0 7,0 20,0 Evaporator set point X1 in cool
User Water Cooling 2239 Water 2 R/W/Z °C 19,0 7,0 20,0 Evaporator set point X2 in cool
User Water 2240 Heating 2241 Status R * * * * Evaporator status
User Water Heating 2242 Inlet R °C -50,0 * 105,0 Evaporator inlet reference T°
User Water Heating 2243 Outlet R °C -50,0 * 105,0 Evaporator outlet reference T°
User Water Heating 2244 Setpoint R °C -50,0 * 105,0 Evaporator set point
User Water Heating 2245 Capacity R °C 0,0 * 100,0 Evaporator cooling capacity
User Water Heating 2246 Air 1 R/W/Z °C -11,0 22,0 50,0 Outside air set point X1 in heat
User Water Heating 2247 Air 2 R/W/Z °C -11,0 30,0 50,0 Outside air set point X2 in heat
User Water Heating 2248 Water 1 R/W/Z °C 40,0 45,0 50,0 Evaporator set point X1 in heat
User Water Heating 2249 Water 2 R/W/Z °C 40,0 45,0 50,0 Evaporator set point X2 in heat
