Page 52 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Pump 2360 Heating Flow 2361 T.In R °C -50,0 * 105,0 Condenser T° inlet
User Pump Heating Flow 2362 T.Out R °C -50,0 * 105,0 Condenser T° outlet
User Pump Heating Flow 2363 P.In R Bar 0,0 * 6,0 Condenser pressure in
User Pump Heating Flow 2364 P.Out R Bar 0,0 * 6,0 Condenser pressure out
User Pump Heating Flow 2365 Delta dT R °C 0,0 * 20,0 Condenser delta T°
User Pump Heating Flow 2366 Delta dP R Bar 0,0 * 6,0 Condenser delta pressure
User Pump Heating Flow 2367 Capacity R % 0,0 * 100,0 Condenser flow capacity
User Pump Heating Flow 2368 Flow R m3 0,0 * 100,0 Condenser flow meter
User Pump Heating Flow 2369 Flow R * 0 * 1 Condenser flow switch
User 2400 Compressor 2410 Circuit 1 2411 Condensing R Bar -50,0 * 105,0 Condensing pressure circuit 1
User Compressor Circuit 1 2412 Condensing R °C -50,0 * 105,0 Condensing T° circuit 1
User Compressor Circuit 1 2413 Saturated R Bar -50,0 * 105,0 Saturated pressure circuit 1
User Compressor Circuit 1 2414 Saturated R °C -50,0 * 105,0 Saturated T° circuit 1
User Compressor Circuit 1 2415 Liquid R °C -50,0 * 105,0 Liquid T° circuit 1
User Compressor Circuit 1 2416 Suction R °C -50,0 * 105,0 Suction T° circuit 1
User Compressor Circuit 1 2417 Discharge 1 R °C -50,0 * 150,0 Discharge T° 1 circuit 1
User Compressor Circuit 1 2418 Discharge 2 R °C -50,0 * 150,0 Discharge T° 2 circuit 1
User Compressor 2420 Cir.1 Comp.1 2421 Config R * * * *
Configuration compressor 1
User Compressor Cir.1 Comp.1 2422 Status R * * * * Status compressor 1 circuit 1
User Compressor Cir.1 Comp.1 2423 Sw State R * 0 * 1 Input compressor 1 circuit 1
User Compressor Cir.1 Comp.1 2424 Output R * 0 * 1 Output compressor 1 circuit 1
User Compressor Cir.1 Comp.1 2425 Capacity R % 0,0 * 100,0 Capacity compressor 1 circuit 1
User Compressor Cir.1 Comp.1 2426 Time R HH 0 * 99999
