Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
MUL41E-0610/06-2011 Page 53
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Compressor 2430 Cir.1 Comp.2 2431 Config R * * * *
Configuration compressor 2
circuit 1
User Compressor Cir.1 Comp.2 2432 Status R * * * * Status compressor 2 circuit 1
User Compressor Cir.1 Comp.2 2433 Sw State R * 0 * 1 Input compressor 2 circuit 1
User Compressor Cir.1 Comp.2 2434 Output R * 0 * 1 Output compressor 2 circuit 1
User Compressor Cir.1 Comp.2 2435 Capacity R % 0,0 * 100,0 Capacity compressor 2 circuit 1
User Compressor Cir.1 Comp.2 2436 Time R HH 0 * 99999
Hour counter compressor 2
circuit 1
User Compressor Cir.1 Comp.2 2437 Start H R * 0 * 999
Start counter high compressor
2 circuit 1
(example : 123)
User Compressor Cir.1 Comp.2 2438 Start L R * 0 * 999
Start counter low compressor 2
circuit 1
(example 456)
User Compressor 2440 Cir.1 Comp.3 2441 Config R * * * *
Configuration compressor 3
circuit 1
User Compressor Cir.1 Comp.3 2442 Status R * * * * Status compressor 3 circuit 1
User Compressor Cir.1 Comp.3 2443 Sw State R * 0 * 1 Input compressor 3 circuit 1
User Compressor Cir.1 Comp.3 2444 Output R * 0 * 1 Output compressor 3 circuit 1
User Compressor Cir.1 Comp.3 2445 Capacity R % 0,0 * 100,0 Capacity compressor 3 circuit 1
User Compressor Cir.1 Comp.3 2446 Time R HH 0 * 99999
Hour counter compressor 3
circuit 1
User Compressor Cir.1 Comp.3 2447 Start H R * 0 * 999
Start counter high compressor
3 circuit 1
(example : 123)
User Compressor Cir.1 Comp.3 2448 Start L R * 0 * 999
Start counter low compressor 3
circuit 1
(example 456)
User Compressor 2450 Circuit 2 2451 Condensing R Bar -50,0 * 105,0 Condensing pressure circuit 2
User Compressor Circuit 2 2452 Condensing R °C -50,0 * 105,0 Condensing T° circuit 2
User Compressor Circuit 2 2453 Saturated R Bar -50,0 * 105,0 Saturated pressure circuit 2
User Compressor Circuit 2 2454 Saturated R °C -50,0 * 105,0 Saturated T° circuit 2
User Compressor Circuit 2 2455 Liquid R °C -50,0 * 105,0 Liquid T° circuit 2
User Compressor Circuit 2 2456 Suction R °C -50,0 * 105,0 Suction T° circuit 2
User Compressor Circuit 2 2457 Discharge 1 R °C -50,0 * 150,0 Discharge T° 1 circuit 2
User Compressor Circuit 2 2458 Discharge 2 R °C -50,0 * 150,0 Discharge T° 2 circuit 2
