Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
Page 54 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Compressor 2460 Cir.2 Comp.1 2461 Config R * * * *
Configuration compressor 1
circuit 2
User Compressor Cir.2 Comp.1 2462 Status R * * * * Status compressor 1 circuit 2
User Compressor Cir.2 Comp.1 2463 Sw State R * 0 * 1 Input compressor 1 circuit 2
User Compressor Cir.2 Comp.1 2464 Output R * 0 * 1 Output compressor 1 circuit 2
User Compressor Cir.2 Comp.1 2465 Capacity R % 0,0 * 100,0 Capacity compressor 1 circuit 2
User Compressor Cir.2 Comp.1 2466 Time R HH 0 * 99999
Hour counter compressor 1
circuit 2
User Compressor Cir.2 Comp.1 2467 Start H R * 0 * 999
Start counter high compressor
1 circuit 2
(example : 123)
User Compressor Cir.2 Comp.1 2468 Start L R * 0 * 999
Start counter low compressor 1
circuit 2
(example 456)
User Compressor 2470 Cir.2 Comp.2 2471 Config R * * * *
Configuration compressor 2
circuit 2
User Compressor Cir.2 Comp.2 2472 Status R * * * * Status compressor 2 circuit 2
User Compressor Cir.2 Comp.2 2473 Sw State R * 0 * 1 Input compressor 2 circuit 2
User Compressor Cir.2 Comp.2 2474 Output R * 0 * 1 Output compressor 2 circuit 2
User Compressor Cir.2 Comp.2 2475 Capacity R % 0,0 * 100,0 Capacity compressor 2 circuit 2
User Compressor Cir.2 Comp.2 2476 Time R HH 0 * 99999
Hour counter compressor 2
circuit 2
User Compressor Cir.2 Comp.2 2477 Start H R * 0 * 999
Start counter high compressor
2 circuit 2
(example : 123)
User Compressor Cir.2 Comp.2 2478 Start L R * 0 * 999
Start counter low compressor 2
circuit 2
(example 456)
User Compressor 2480 Cir.2 Comp.3 2481 Config R * * * *
Configuration compressor 3
circuit 2
User Compressor Cir.2 Comp.3 2482 Status R * * * * Status compressor 3 circuit 2
User Compressor Cir.2 Comp.3 2483 Sw State R * 0 * 1 Input compressor 3 circuit 2
User Compressor Cir.2 Comp.3 2484 Output R * 0 * 1 Output compressor 3 circuit 2
User Compressor Cir.2 Comp.3 2485 Capacity R % 0,0 * 100,0 Capacity compressor 3 circuit 2
User Compressor Cir.2 Comp.3 2486 Time R HH 0 * 99999
Hour counter compressor 3
circuit 2
User Compressor Cir.2 Comp.3 2487 Start H R * 0 * 999
Start counter high compressor
3 circuit 2
(example : 123)
User Compressor Cir.2 Comp.3 2488 Start L R * 0 * 999
Start counter low compressor 3
circuit 2
(example 456)
