Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
MUL41E-0610/06-2011 Page 55
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Compressor 2490 Other 2491 Sw HP C1 R * 0 * 1 Safety pressure switch circuit 1
User Compressor Other 2492 Sw HP C2 R * 0 * 1 Safety pressure switch circuit 2
User Compressor Other 2493 V4V C1 R * 0 * 1 Reversing valve circuit 1
User Compressor Other 2494 V4V C2 R * 0 * 1 Reversing valve circuit 2
User 2500 Condenser 2510 Circuit 1 2511 Config R * * * *
Configuration condenser circuit
1
User Condenser Circuit 1 2512 Status R * * * * Status condenser circuit 1
User Condenser Circuit 1 2513 Sw State R * 0 * 1 Input condenser circuit 1
User Condenser Circuit 1 2514 Input R °C -50,0 * 67,0 Condensing T° circuit 1
User Condenser Circuit 1 2515 Setpoint R °C 25,0 * 45,0 Condensing T° set point
User Condenser Circuit 1 2516 Capacity R % 0,0 * 100,0
Condensing fan capacity circuit
1
User Condenser Circuit 1 2517 Speed Low R * 0 * 1
Condensing fan low speed
circuit 1
User Condenser Circuit 1 2518 Speed High R * 0 * 1
Condensing fan high speed
circuit 1
User Condenser 2520 Circuit 2 2521 Config R * * * *
Configuration condenser circuit
2
User Condenser Circuit 2 2522 Status R * * * * Status condenser circuit 2
User Condenser Circuit 2 2523 Sw State R * 0 * 1 Input condenser circuit 2
User Condenser Circuit 2 2524 Input R °C -50,0 * 67,0 Condensing T° circuit 2
User Condenser Circuit 2 2525 Setpoint R °C 25,0 * 45,0 Condensing T° set point
User Condenser Circuit 2 2526 Capacity R % 0,0 * 100,0
Condensing fan capacity circuit
2
User Condenser Circuit 2 2527 Speed Low R * 0 * 1
Condensing fan low speed
circuit 2
User Condenser Circuit 2 2528 Speed High R * 0 * 1
Condensing fan high speed
circuit 2
User Condenser 2530 Circuit 1/2 2531 Config R * * * *
Configuration condenser circuit
1&2
User Condenser Circuit 1/2 2532 Status R * * * * Status condenser circuit 1&2
User Condenser Circuit 1/2 2533 Sw State R * 0 * 1 Input condenser circuit 1&2
User Condenser Circuit 1/2 2534 Capacity R % 0,0 * 100,0
Condensing capacity circuit
1&2
User Condenser 2540 Fan 2541 Outside R °C -50,0 * 105,0 Outside air T°
User Condenser Fan 2542 Capacity Max R % 0,0 * 100,0
Condenser fan capacity
maximum
User Condenser Fan 2543 Unloading R/W °C 50,0 * 65,0 Condenser unloading T°
User Condenser Fan 2544 Mode R/WZ *
0=Not Set,
1=Quiet,
2=Quiet++.
Condenser fan accoustic mode
User Condenser Fan 2545 Noise R/WZ dBa 82,0 * 94,0 Condenser fan accoustic noise
