Page 56 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Condenser 2550 Water 2551 Inlet C1 R * -50,0 * 105,0 Condenser inlet T° circuit 1
User Condenser Water 2552 Outlet C1 R * -50,0 * 105,0 Condenser outlet T° circuit 1
User Condenser Water 2553 Inlet C2 R * -50,0 * 105,0 Condenser inlet T° circuit 2
User Condenser Water 2554 Outlet C2 R * -50,0 * 105,0 Condenser outlet T° circuit 2
User 2600 EEV 2610 Circuit 1 2611 Config R * * * * *
User EEV Circuit 1 2612 Status R * * * * *
User EEV Circuit 1 2613 Saturated R * * * * *
User EEV Circuit 1 2614 Saturated R * * * * *
User EEV Circuit 1 2615 Suction R * * * * *
User EEV Circuit 1 2616 Superheat R * * * * *
User EEV Circuit 1 2617 Capacity R * * * * *
User EEV Circuit 1 2618 Step R * * * * *
User EEV Circuit 1 2619 Power R * * * * *
User EEV 2620 Circuit 2 2621 Config R * * * * *
User EEV Circuit 2 2622 Status R * * * * *
User EEV Circuit 2 2623 Saturated R * * * * *
User EEV Circuit 2 2624 Saturated R * * * * *
User EEV Circuit 2 2625 Suction R * * * * *
User EEV Circuit 2 2626 Superheat R * * * * *
User EEV Circuit 2 2627 Capacity R * * * * *
User EEV Circuit 2 2628 Step R * * * * *
User EEV Circuit 2 2629 Power R * * * * *
User 2700 Other 2710 Freecooling 2711 Config R * * * * Configuration of the freecooling
User Other Freecooling 2712 Status R * * * * Status of the freecooling
User Other Freecooling 2713 Sw State R * 0 * 1 Input of the freecooling
User Other Freecooling 2714 Outside R °C -50,0 * 105,0 Outside air T°
User Other Freecooling 2715 Inlet R °C -50,0 * 105,0 Inlet coil water T°
User Other Freecooling 2716 Outlet R °C -50,0 * 105,0 Outlet coil water T°
User Other Freecooling 2717 Capacity R % 0,0 * 100,0 Freecooling fan capacity
User Other Freecooling 2718 Valve R * 0 * 1 Freecooling valve
User Other 2720 FP Correct 2721 Config R * * * *
