Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
MUL41E-0610/06-2011 Page 57
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
User Other 2730 Heater Elec 2731 Config R * * * *
Configuration of the electrical
heater
User Other Heater Elec 2732 Status R * * * * Status of the electrical heater
User Other Heater Elec 2733 Outlet R °C -50,0 * 105,0 Evaporator outler T°
User Other Heater Elec 2734 Capacity R % 0,0 * 100,0 Electrical heater capacity
User Other Heater Elec 2735 Sw State R * 0 * 1 Electrical heater input
User Other Heater Elec 2736 Output 1 R * 0 * 1 Electrical heater output 1
User Other Heater Elec 2737 Output 2 R * 0 * 1 Electrical heater output 2
User Other Heater Elec 2738 Output 3 R * 0 * 1 Electrical heater output 3
User Other Heater Elec 2739 Output 4 R * 0 * 1 Electrical heater output 4
User 2800 Link 2810 Master/Slave 2811 Config R * * * *
Configuration of the
master/slave link
User Link Master/Slave 2812 Status R * * * * Status of the master/slave link
User Link Master/Slave 2813 Id R * 1 * 8
Identification number of the
BM60 board
User Link Master/Slave 2814 Outside R °C -50,0 * 105,0 Outside air reference T°
User Link Master/Slave 2815 Inlet R °C -50,0 * 105,0 Evaporator inlet reference T°
User Link Master/Slave 2816 Outlet R °C -50,0 * 105,0 Evaporator outlet reference T°
User Link Master/Slave 2817 Priority R * 1 * 8 Unit number priority to start
User Link Master/Slave 2818 Standby R * 1 * 8 Unit number in standby
User Link Master/Slave 2819 Next Start R * 1 * 8 Unit number to start next
User Link 2820 BMS 2821 Id R * 1 * 99 Identification number of the unit
User Link BMS 2822 Status R * * * * Status of the BMS
User Link BMS 2823 Watchdog R * 0 * 32000 Watchdog timer
User Link BMS 2824 Outside R °C -50,0 * 105,0 Outside air BMS T°
User Link BMS 2825 Inlet R °C -50,0 * 105,0 Evaporator inlet BMS T°
User Link BMS 2826 Outlet R °C -50,0 * 105,0 Evaporator outlet BMS T°
User Link BMS 2827 Inoc R * 0 * 1 *
