Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
Page 58 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
3000 Expert 3100 Unit 3110 General 3111 On/Off R/W 0 0 * 1 General On/Off
Expert Unit General 3112 Sw On/Off R/W 0 0 * 1 Remote On/Off
Expert Unit General 3113 Run R/W /Z * 0 1 1 Enable
Expert Unit General 3114 Reset Alarm R/W * 0 0 1 Reset the active alarm(s)
Expert Unit General 3115 Clear Alarm R/W * 0 0 1 Clear the historic of alarm(s)
Expert Unit General 3116 Elec.Box R °C -50,0 * 105,0 Electrical box T°
Expert Unit General 3117 Status R * * * * General status
Expert Unit General 3118 Test R/W *
0=Not set,
1=Quickly,
2=Wizard,
3=Daily Task,
4=Weekly Task,
5=Defrost C1,
6=Defrost C2,
7=Defrost C1&2,
8=HP C1,
9=HP C2,
10=HP C1&2.
Test
Expert Unit General 3119 Restore R/W *
0=Not set,
1=DC+Bms,
2=Schedule,
3=Factory,
4=Store User,
5=Restore User.
Restore the settings
parameters
Expert Unit 3120 Configuration 3121 Range R/W *
0=Not set,
1=EAC, 2=EAR, 3=NAC, 4=NAH, 5=MWC, 6=NWC, 8=MRC.
Unit range configuration
Expert Unit Configuration 3122 Size R/W * * * * Unit size configuration
Expert Unit Configuration 3123 EEV R/W * * * *
Electronique expansion valve
cconfiguration
Expert Unit Configuration 3124 Glycol R/W % 0 0 50 Glycol rate configuration
Expert Unit 3130 Cust.Relay 3131 BM.NO7 R/W *
0=Not Set,
1=Alarm,
2=Fault,
3=Alarm C1,
4=Alarm C2,
5=Alarm Cond,
6=Alarm Pump Evap,
7=Alarm Flow Evap,
8=Enable,
9=Avaible,
10=Run,
11=Run 100%,
12=Cooling Mode,
13=Heating Mode,
14=Dead Zone Mode,
15=Zone 0,
16=Zone 1,
17=Zone 2,
18=Zone 3,
19=Zone 4,
20=Zone 5,
21=Zone 6,
22=Mode A,
23=Mode B,
24=Mode C,
25=Mode D,
26=Mode BMS,
27=Elec.Heater 1,
28=Elec.Heater 2,
29=Elec.Heater 3,
30=Elec.Heater 4,
31=Free BM.NO7,
32=Free BE.NO1,
33=Free BE.NO2,
34=Free BE.NO3,
35=Free BE.NO4,
36=Not Used,
37=Not Used,
38=Not Used,
39=Not Used,
40=Freecooling,
41=NSR 1, 42=NSR 2,
43=NSR 3, 44=NSR 4,
45=NSR 5.
Configuration of the free output
BM.NO7
