CLIMATIC™ 60 – AIRCOOLED CHILLERS
Page 60 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
Expert Unit 3160 Option 3161 Pump Cool R/W *
0=Not Set,
1=Single=,
3=Double=,
4=Double%.
Evaporator pump(s)
configuration
Expert Unit Option 3162 Pump Heat R/W *
3=Double=,
4=Double%.
Condenser pump(s)
configuration
Expert Unit Option 3163 FP Cos R/W * 0=No, 1=Yes.
configuration
Expert Unit Option 3164 Freecooling R/W * 0=No, 1=Yes. Freecooling configuration
Expert Unit Option 3165 Power meter R/W *
0=Not Set,
1=1,.,.,
2=.,2,.,
3=1,2,.,.
Power meter configuration
Expert Unit Option 3166 Heater Elec R/W * 0=No, 1=Yes. Electrical heater configuration
Expert Unit Option 3167 Remote DC R/W * 0=No, 1=Yes. Remote DC60 configuration
Expert 3200 Water 3210 Temperature 3211 Inlet R °C -50,0 * 105,0 Evaporator inlet probe T°
Expert Water Temperature 3212 Inlet Ref R °C -50,0 * 105,0 Evaporator inlet reference T°
Expert Water Temperature 3213 Outlet R °C -50,0 * 105,0 Evaporator outlet probe T°
Expert Water Temperature 3214 Outlet Ref R °C -50,0 * 105,0 Evaporator outlet reference T°
Expert Water Temperature 3215 Delta T° R °C -50,0 * 105,0
Evaporator delta T° (Inlet-
Outlet)
Expert Water Temperature 3216 Setpoint R °C -50,0 * 105,0 Evaporator set point
Expert Water Temperature 3217 Capacity R % -50,0 * 105,0 Evaporator capacity
Expert Water Temperature 3218 Flow R * 0 * 1 Evaporator flow switch
Expert Water 3220 Changeover 3221 Status R * * * * Changeover status
Expert Water Changeover 3222 Outside R °C -50,0 * 105,0 Outside air probe T°
Expert Water Changeover 3223 Outside Ref R °C -50,0 * 105,0 Outside air reference T°
Expert Water Changeover 3224 Mode R/W/Z *
3=Auto,
4=Dead zone.
Changeover mode
Expert Water Changeover 3225 Winter R/W °C -10,0 18,0 30,0
Winter T° to swap in heating
mode
Expert Water Changeover 3226 Summer R/W °C 19,0 23,0 30,0
Summer T° to swap in cooling
mode
