Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
Expert Water 3230 Cooling 3231 Status R * * * * Evaporator status
Expert Water Cooling 3232 Inlet R °C -50,0 * 105,0 Evaporator inlet reference T°
Expert Water Cooling 3233 Outlet R °C -50,0 * 105,0 Evaporator outlet reference T°
Expert Water Cooling 3234 Setpoint R °C -50,0 * 105,0 Evaporator set point
Expert Water Cooling 3235 Capacity R % 0,0 * 100,0 Evaporator cooling capacity
Expert Water Cooling 3236 Air 1 R/W/Z °C -11,0 22,0 50,0 Outside air set point X1 in cool
Expert Water Cooling 3237 Air 2 R/W/Z °C -11,0 30,0 50,0 Outside air set point X2 in cool
Expert Water Cooling 3238 Water 1 R/W/Z °C 19,0 7,0 20,0 Evaporator set point X1 in cool
Expert Water Cooling 3239 Water 2 R/W/Z °C 19,0 7,0 20,0 Evaporator set point X2 in cool
Expert Water 3240 Heating 3241 Status R * * * * Evaporator status
Expert Water Heating 3242 Inlet R °C -50,0 * 105,0 Evaporator inlet reference T°
Expert Water Heating 3243 Outlet R °C -50,0 * 105,0 Evaporator outlet reference T°
Expert Water Heating 3244 Setpoint R °C -50,0 * 105,0 Evaporator set point
Expert Water Heating 3245 Capacity R % 0,0 * 100,0 Evaporator cooling capacity
Expert Water Heating 3246 Air 1 R/W/Z °C -11,0 22,0 50,0 Outside air set point X1 in heat
Expert Water Heating 3247 Air 2 R/W/Z °C -11,0 30,0 50,0 Outside air set point X2 in heat
Expert Water Heating 3248 Water 1 R/W/Z °C 40,0 45,0 50,0 Evaporator set point X1 in heat
Expert Water Heating 3249 Water 2 R/W/Z °C 40,0 45,0 50,0 Evaporator set point X2 in heat
Expert Water 3250 Custom 3251 Sp 4/20mA R °C 4,0 * 20,0 External evaporator set point
Expert Water Custom 3252 Sp +/-0.5°C R °C -0,5 * 0,5
External offset evaporator set
point
Expert Water Custom 3253 2nd Sp R * 0 * 1 Second set point switch status
Expert Water 3260 Control 3261 Cool dT° R/W °C 1,0 5,0 20,0 Evaporator cooling delta T°
Expert Water Control 3262 Heat dT° R/W °C 1,0 5,0 20,0 Evaporator heating delta T°
Expert Water Control 3263 Reactivity R/W * 1 30 120 Evaporator water reactivity
Expert Water 3270 Safety 3271 Cool Low R/W °C 3,0 5,0 55,0
Evaporator cooling low safety
T°
Expert Water Safety 3272 Cool High R/W °C 19,0 55,0 55,0
Evaporator cooling high safety
T°
Expert Water Safety 3273 Heat Low R/W °C 3,0 5,0 55,0
Evaporator heating low safety
T°
Expert Water Safety 3274 Heat High R/W °C 19,0 55,0 55,0
Evaporator heating high safety
T°
