Lennox CLIMATIC 60

CLIMATIC™ 60 – AIRCOOLED CHILLERS
MUL41E-0610/06-2011 Page 63
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
Expert Pump 3360 Heating Flow 3361 T.In R °C -50,0 * 105,0 Condenser T° inlet
Expert Pump Heating Flow 3362 T.Out R °C -50,0 * 105,0 Condenser T° outlet
Expert Pump Heating Flow 3363 P.In R Bar 0,0 * 6,0 Condenser pressure in
Expert Pump Heating Flow 3364 P.Out R Bar 0,0 * 6,0 Condenser pressure out
Expert Pump Heating Flow 3365 Delta dT R °C 0,0 * 20,0 Condenser delta T°
Expert Pump Heating Flow 3366 Delta dP R Bar 0,0 * 6,0 Condenser delta pressure
Expert Pump Heating Flow 3367 Capacity R % 0,0 * 100,0 Condenser flow capacity
Expert Pump Heating Flow 3368 Flow R m3 0,0 * 100,0 Condenser flow meter
Expert Pump Heating Flow 3369 Flow R * 0 * 1 Condenser flow switch
Expert Pump 3370 Cooling Control 3371 Enable R/W/Z *
0=Not Set,
1=Not Used,
2=Prio.P1On,
3=Prio.P1Auto,
4=Prio.P2On,
5=Prio.P2Auto,
6=No Prio.On,
7=No Prio.Auto.
Evaporator pump(s) enable
Expert Pump Cooling Control 3372 Mode R/W *
0=Not Used,
1=Fix Speed,
2=Fix dT,
3=Fix dP,
4=Fix P.Out.
Evaporator pump(s) operating
mode
Expert Pump Cooling Control 3373 Reset R/W * 0=Not Set, 1=1,.,., 2=.,2,.,
Evaporator pump(s) reset
counter
Expert Pump Cooling Control 3374 Delta dT R/W °C 2,0 * 10,0
Evaporator variable flow delta
T°
Expert Pump Cooling Control 3375 Delta dP R/W Bar 1,0 1,0 2,0
Evaporator variable flow delta
pressure
Expert Pump Cooling Control 3376 P.Out R/W Bar 0,5 1,0 2,0
Evaporator variable flow output
pressure
Expert Pump Cooling Control 3377 Flow Min R/W % 60,0 60,0 100,0
Evaporator variable flow
minimum
Expert Pump Cooling Control 3378 Flow Max R/W % 60,0 100,0 100,0
Evaporator variable flow
maximum
Expert Pump 3380 Heating Control 3381 Enable R/W/Z *
0=Not Set,
1=Not Used,
2=Prio.P1On,
3=Prio.P1Auto,
4=Prio.P2On,
5=Prio.P2Auto,
6=No Prio.On,
7=No Prio.Auto.
condenser pump(s) enable
Expert Pump Heating Control 3382 Mode R/W *
0=Not Used,
1=Fix Speed,
2=Fix dT,
3=Fix dP,
4=Fix P.Out.
condenser pump(s) operating
mode
Expert Pump Heating Control 3383 Reset R/W *
0=Not Set,
1=1,.,., 2=.,2,.,
condenser pump(s) reset
counter
Expert Pump Heating Control 3384 Delta dT R/W °C 2,0 * 10,0
condenser variable flow delta
T°
Expert Pump Heating Control 3385 Delta dP R/W Bar 1,0 1,0 2,0
condenser variable flow delta
pressure
Expert Pump Heating Control 3386 P.Out R/W Bar 0,5 1,0 2,0
condenser variable flow output
pressure
Expert Pump Heating Control 3387 Flow Min R/W % 60,0 60,0 100,0
condenser variable flow
minimum
Expert Pump Heating Control 3388 Flow Max R/W % 60,0 100,0 100,0
condenser variable flow
maximum
