CLIMATIC™ 60 – AIRCOOLED CHILLERS
Page 64 MUL41E-0610/06-2011
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
Expert 3400 Compressor 3410 Circuit 1 3411 Condensing R Bar -50,0 * 105,0 Condensing pressure circuit 1
Expert Compressor Circuit 1 3412 Condensing R °C -50,0 * 105,0 Condensing T° circuit 1
Expert Compressor Circuit 1 3413 Saturated R Bar -50,0 * 105,0 Saturated pressure circuit 1
Expert Compressor Circuit 1 3414 Saturated R °C -50,0 * 105,0 Saturated T° circuit 1
Expert Compressor Circuit 1 3415 Liquid R °C -50,0 * 105,0 Liquid T° circuit 1
Expert Compressor Circuit 1 3416 Suction R °C -50,0 * 105,0 Suction T° circuit 1
Expert Compressor Circuit 1 3417 Discharge 1 R °C -50,0 * 150,0 Discharge T° 1 circuit 1
Expert Compressor Circuit 1 3418 Discharge 2 R °C -50,0 * 150,0 Discharge T° 2 circuit 1
Expert Compressor 3420 Circuit 2 3421 Condensing R Bar -50,0 * 105,0 Condensing pressure circuit 2
Expert Compressor Circuit 2 3422 Condensing R °C -50,0 * 105,0 Condensing T° circuit 2
Expert Compressor Circuit 2 3423 Saturated R Bar -50,0 * 105,0 Saturated pressure circuit 2
Expert Compressor Circuit 2 3424 Saturated R °C -50,0 * 105,0 Saturated T° circuit 2
Expert Compressor Circuit 2 3425 Liquid R °C -50,0 * 105,0 Liquid T° circuit 2
Expert Compressor Circuit 2 3426 Suction R °C -50,0 * 105,0 Suction T° circuit 2
Expert Compressor Circuit 2 3427 Discharge 1 R °C -50,0 * 150,0 Discharge T° 1 circuit 2
Expert Compressor Circuit 2 3428 Discharge 2 R °C -50,0 * 150,0 Discharge T° 2 circuit 2
Expert Compressor 3430 Enable 3431 Enable C1 R/W/Z *
0=Not Set,
1=1,.,., 2=.,2,., 3=1,2,., 4=.,.,3, 5=1,.,3, 6=.,2,3, 7=1,2,3.
Compressor(s) enable circuit 1
Expert Compressor Enable 3432 Enable C2 R/W/Z *
0=Not Set,
1=1,.,., 2=.,2,., 3=1,2,., 4=.,.,3, 5=1,.,3, 6=.,2,3, 7=1,2,3.
Compressor(s) enable circuit 2
Expert Compressor Enable 3433 Reset C1 R/W *
0=Not Set,
1=1,.,., 2=.,2,., 3=1,2,., 4=.,.,3, 5=1,.,3, 6=.,2,3, 7=1,2,3.
Compressor(s) reset counter
circuit 1
Expert Compressor Enable 3434 Reset C2 R/W *
0=Not Set,
1=1,.,., 2=.,2,., 3=1,2,., 4=.,.,3, 5=1,.,3, 6=.,2,3, 7=1,2,3.
Compressor(s) reset counter
circuit 2
Expert Compressor Enable 3435 Priority R/W *
0=Not Used,
1=Prio.C1,
2=Prio.C2,
3=Auto.
Compressor(s) circuit priority
Expert Compressor 3440 Safety 3441 Saturation R/W °C -6,0 -6,0 5,0 Evaporator saturation safety T°
Expert Compressor Safety 3442 Unloading R/W °C 50,0 63,0 65,0 Condenser unloading safety T°
Expert Compressor Safety 3443 Discharge R/W °C 90,0 110,0 150,0
Compressor discharge safety
T°
