Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
Expert 3500 Condenser 3510 Circuit 1 3511 Config R * * * *
Configuration condenser circuit
1
Expert Condenser Circuit 1 3512 Status R * * * * Status condenser circuit 1
Expert Condenser Circuit 1 3513 Sw State R * 0 * 1 Input condenser circuit 1
Expert Condenser Circuit 1 3514 Input R °C -50,0 * 67,0 Condensing T° circuit 1
Expert Condenser Circuit 1 3515 Setpoint R °C 25,0 * 45,0 Condensing T° set point
Expert Condenser Circuit 1 3516 Capacity R % 0,0 * 100,0
Condensing fan capacity circuit
1
Expert Condenser Circuit 1 3517 Speed Low R * 0 * 1
Condensing fan low speed
circuit 1
Expert Condenser Circuit 1 3518 Speed High R * 0 * 1
Condensing fan high speed
circuit 1
Expert Condenser 3520 Circuit 2 3521 Config R * * * *
Configuration condenser circuit
2
Expert Condenser Circuit 2 3522 Status R * * * * Status condenser circuit 2
Expert Condenser Circuit 2 3523 Sw State R * 0 * 1 Input condenser circuit 2
Expert Condenser Circuit 2 3524 Input R °C -50,0 * 67,0 Condensing T° circuit 2
Expert Condenser Circuit 2 3525 Setpoint R °C 25,0 * 45,0 Condensing T° set point
Expert Condenser Circuit 2 3526 Capacity R % 0,0 * 100,0
Condensing fan capacity circuit
2
Expert Condenser Circuit 2 3527 Speed Low R * 0 * 1
Condensing fan low speed
circuit 2
Expert Condenser Circuit 2 3528 Speed High R * 0 * 1
Condensing fan high speed
circuit 2
Expert Condenser 3530 Circuit 1/2 3531 Config R * * * *
Configuration condenser circuit
1&2
Expert Condenser Circuit 1/2 3532 Status R * * * * Status condenser circuit 1&2
Expert Condenser Circuit 1/2 3533 Sw State R * 0 * 1 Input condenser circuit 1&2
Expert Condenser Circuit 1/2 3534 Input R °C 0,0 * 100,0
Condensing capacity circuit
1&2
Expert Condenser Circuit 1/2 3535 Setpoint R °C * * * *
Expert Condenser Circuit 1/2 3536 Capacity R % * * * *
Expert Condenser 3540 Fan 3541 Outside R °C -50,0 * 105,0 Outside air T°
Expert Condenser Fan 3542 Capacity Max R % 0,0 * 100,0
Condenser fan capacity
maximum
Expert Condenser Fan 3543 Unloading R °C 50,0 * 65,0 Condenser unloading T°
Expert Condenser Fan 3544 Mode R/W *
0=Not Set,
1=Quiet,
2=Quiet++.
Condenser fan accoustic mode
Expert Condenser Fan 3545 Noise R/W dBa 82,0 * 94,0 Condenser fan accoustic noise
Expert Condenser Fan 3546 Setpoint R/W °C 35,0 40,0 45,0 Condenser fan set point
