CLIMATIC™ 60 – AIRCOOLED CHILLERS
MUL41E-0610/06-2011 Page 67
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
Expert EEV 3630 Control 3631 Superheat R/W * * * * *
Expert 3700 Other 3710 Freecooling 3711 Config R * * * * Configuration of the freecooling
Expert Other Freecooling 3712 Status R * * * * Status of the freecooling
Expert Other Freecooling 3713 Sw State R * 0 * 1 Input of the freecooling
Expert Other Freecooling 3714 Outside R °C -50,0 * 105,0 Outside air T°
Expert Other Freecooling 3715 Inlet R °C -50,0 * 105,0 Inlet coil water T°
Expert Other Freecooling 3716 Outlet R °C -50,0 * 105,0 Outlet coil water T°
Expert Other Freecooling 3717 Capacity R % 0,0 * 100,0 Freecooling fan capacity
Expert Other Freecooling 3718 Valve R * 0 * 1 Freecooling valve
Expert Other 3720 FP Correct 3721 Config R * * * *
Configuration of the power
factor correction
Expert Other FP Correct 3722 Status R * * * *
Status of the power factor
Expert Other FP Correct 3723 Sw State R * 0 * 1
Input of the power factor
correction
Expert Other 3730 Heater Elec 3731 Config R * * * *
Configuration of the electrical
Expert Other Heater Elec 3732 Status R * * * * Status of the electrical heater
Expert Other Heater Elec 3733 Outlet R °C -50,0 * 105,0 Evaporator outler T°
Expert Other Heater Elec 3734 Capacity R % 0,0 * 100,0 Electrical heater capacity
Expert Other Heater Elec 3735 Sw State R * 0 * 1 Electrical heater input
Expert Other Heater Elec 3736 Output 1 R * 0 * 1 Electrical heater output 1
Expert Other Heater Elec 3737 Output 2 R * 0 * 1 Electrical heater output 2
Expert Other Heater Elec 3738 Output 3 R * 0 * 1 Electrical heater output 3
Expert Other Heater Elec 3739 Output 4 R * 0 * 1 Electrical heater output 4
Expert 3800 Link 3810 Master/Slave 3811 Status R * * * * Status of the master/slave link
Expert Link Master/Slave 3812 Outside R °C -50,0 * 105,0 Outside air reference T°
Expert Link Master/Slave 3813 Inlet R °C -50,0 * 105,0 Evaporator inlet reference T°
Expert Link Master/Slave 3814 Outlet R °C -50,0 * 105,0 Evaporator outlet reference T°
Expert Link Master/Slave 3815 Number R/W * 1 * 8 Number of units linked
Expert Link Master/Slave 3816 Type R/W *
0=Not Set,
1=Not Used,
2=CascadTwins,
4=BackupTwins,
5=BackupChain,
6=RolBackupTwins,
Master/slave configuration
Expert Link Master/Slave 3817 T°Air R/W * 0=Not Used, 1=Master, 2=Average. Outside air T° configuration
Expert Link Master/Slave 3818 T°Water R/W * 0=Not Used, 1=Master, 2=Average.
Evaporator water T°
