Lennox Energence LCH User Manual

Energence
®

RATINGS
NOTE - For Temperatures and Capacities not shown in tables, see bulletin - Cooling Unit Rating Table Correction Factor Data in Miscellaneous Engineering Data section.
26 KW LCH092H4B (1ST STAGE)
Entering
Wet
Bulb
Temper-
ature
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
18.3°C 23.9°C 29.4°C 35°C
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Dry Bulb Dry Bulb Dry Bulb Dry Bulb
L/s kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C
17.2°C
1135 12.4 1.62 0.7 0.85 1 11.9 1.83 0.71 0.87 1 11.3 2.06 0.72 0.89 1 10.6 2.33 0.74 0.93 1
1415 13 1.62 0.76 0.95 1 12.5 1.83 0.77 0.98 1 11.8 2.07 0.78 1 1 11.2 2.33 0.81 1 1
1700 13.6 1.63 0.81 1 1 13 1.84 0.84 1 1 12.5 2.07 0.86 1 1 11.8 2.33 0.9 1 1
19.4°C
1135 13.2 1.62 0.55 0.68 0.81 12.6 1.83 0.56 0.69 0.83 12 2.07 0.56 0.7 0.85 11.3 2.33 0.56 0.72 0.89
1415 13.8 1.63 0.59 0.74 0.91 13.2 1.84 0.6 0.75 0.94 12.5 2.07 0.6 0.76 0.97 11.8 2.33 0.61 0.78 1
1700 14.2 1.63 0.61 0.79 1 13.6 1.84 0.63 0.81 1 12.9 2.07 0.63 0.84 1 12.1 2.33 0.65 0.87 1
21.7°C
1135 13.9 1.63 0.41 0.53 0.66 13.3 1.84 0.42 0.53 0.67 12.7 2.07 0.42 0.55 0.68 12 2.33 0.42 0.56 0.7
1415 14.5 1.63 0.43 0.57 0.72 13.9 1.84 0.44 0.59 0.73 13.2 2.07 0.44 0.59 0.74 12.5 2.33 0.43 0.6 0.76
1700 15 1.64 0.45 0.61 0.77 14.3 1.85 0.44 0.62 0.79 13.5 2.08 0.45 0.63 0.82 12.8 2.34 0.45 0.64 0.84
26 KW LCH092H4B (2ND STAGE)
Entering
Wet
Bulb
Temper-
ature
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
26.7°C 35°C 43.3°C 46°C
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Dry Bulb Dry Bulb Dry Bulb Dry Bulb
L/s kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C
17.2°C
1135 23.2 3.89 0.72 0.88 1 21.3 4.66 0.74 0.93 1 19.3 5.61 0.76 0.98 1 18.8 5.97 .82 1.00 1.00
1415 24.3 3.89 0.78 0.99 1 22.5 4.66 0.81 1 1 20.6 5.62 0.86 1 1 20.1 5.96 .91 1.00 1.00
1700 25.5 3.9 0.85 1 1 23.7 4.67 0.9 1 1 21.6 5.62 0.96 1 1 21.1 5.96 .99 1.00 1.00
19.4°C
1135 24.6 3.9 0.55 0.69 0.84 22.6 4.66 0.57 0.72 0.89 20.5 5.61 0.58 0.74 0.94 19.8 5.96 .61 .81 .94
1415 25.7 3.9 0.6 0.76 0.95 23.6 4.67 0.61 0.78 0.99 21.3 5.62 0.62 0.83 1 20.6 5.96 .67 .90 1.00
1700 26.4 3.91 0.63 0.83 1 24.3 4.67 0.65 0.87 1 22 5.62 0.68 0.94 1 21.2 5.97 .73 .99 1.00
21.7°C
1135 26 3.91 0.41 0.53 0.67 24 4.67 0.42 0.56 0.7 21.8 5.62 0.42 0.57 0.72 21.0 5.96 .43 .61 .73
1415 27.1 3.91 0.43 0.59 0.74 24.9 4.67 0.43 0.6 0.76 22.6 5.62 0.44 0.62 0.8 21.9 5.96 .45 .67 .82
1700 27.9 3.92 0.45 0.62 0.8 25.6 4.68 0.45 0.64 0.84 23.2 5.62 0.46 0.68 0.91 22.4 5.96 .48 .74 .91
Entering
Wet
Bulb
Temper-
ature
Total
Air
Volume
Outdoor Air Temperature Entering Outdoor Coil
48°C 50°C 51.7°C
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Total
Cool
Cap.
Comp.
Motor
Input
Sensible To Total
Ratio (S/T)
Dry Bulb Dry Bulb Dry Bulb
L/s kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C kW kW 24°C 27°C 29°C
17.2°C
1135 18.2 6.25 0.78 1 1 17.7 6.55 0.80 1 1 17.3 6.81 0.81 1 1
1415 19.5 6.25 0.90 1 1 18.9 6.54 0.92 1 1 18.4 6.8 0.94 1 1
1700 20.4 6.25 0.99 1 1 19.8 6.54 1.00 1 1 19.4 6.8 1 1 1
19.4°C
1135 19.2 6.25 0.59 0.76 0.98 18.7 6.55 0.59 0.77 0.99 18.2 6.81 0.6 0.79 1
1415 20.0 6.25 0.64 0.87 1 19.4 6.54 0.65 0.89 1 18.9 6.8 0.66 0.91 1
1700 20.5 6.25 0.70 0.98 1 19.9 6.54 0.71 0.99 1 19.4 6.8 0.71 1 1
21.7°C
1135 20.4 6.25 0.42 0.58 0.74 19.8 6.54 0.42 0.58 0.75 19.3 6.8 0.42 0.59 0.76
1415 21.2 6.24 0.44 0.63 0.84 20.6 6.54 0.44 0.65 0.86 20 6.79 0.45 0.66 0.88
1700 21.7 6.24 0.47 0.69 0.95 21.1 6.54 0.47 0.70 0.97 20.5 6.79 0.47 0.71 0.99
