Page 112 - IOM / ROOF-TOP FLEXY™ Series
ELECTRICAL WIRING DIAGRAMS
DRY CONTACT KIT FOR BMS / REMOTE SET POINT
TCB THERMOSTAT CONTROL BOARD
STOP CONTROL
NIGHT CONTROL
DAY CONTROL
50% LOAD SHEDDING
HEAT LOAD SHEDDING
COLD LOAD SHEDDING
FAULT RESETTING
FILTER FAULT
TREATMENT FAN FAULT
COMPRESSOR FAULT
GAS BURNER FAULT
ELECTRICAL RESISTANCE
FAULT
TOP LIMIT TEMPERATURE
FAULT
BOTTOM LIMIT
TEMPERATURE FAULT
HUMIDIFIER FAULT
FILTER FAULT
TREATMENT FAN FAULT
COMPRESSOR FAULT
GAS BURNER FAULT
ELECTRICAL RESISTANCE FAULT
