Page 5
BLOWER DATA
G60UHV−60C−090 BLOWER PERFORMANCE
0 through 0.80 in. w.g. (0 Through 200 Pa) External Static Pressure Range
Single Side Return Air − Air volumes in bold require field fabricated transition to accommodate 20 x 25 x 1 in. (508 x 635 x 25 mm) clean-
able air filter in order to maintain proper air velocity across the filter.
Blower Control Factory Settings ADJUST − NORM
HEAT − 2
COOL − 4
ADJUST"
Switch
Positions
Speed Switch Positions
2nd Stage HEAT" Speed 2nd Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1475 695 1665 785 1870 880 2050 965 1580 745 1700 800 1920 905 2110 995
NORM (Normal) 1340 630 1515 715 1700 800 1865 880 1435 675 1545 730 1745 825 1920 905
" (Minus) 1205 570 1365 645 1530 720 1680 790 1290 610 1390 655 1570 740 1730 815
ADJUST"
Switch
Positions
1st Stage HEAT" Speed 1st Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1355 640 1535 725 1710 805 1890 890 1070 504 1160 547 1325 625 1490 703
NORM (Normal) 1230 580 1395 660 1555 735 1720 810 955 450 1060 500 1210 570 1325 625
" (Minus) 1105 520 1255 590 1400 660 1550 730 860 405 935 441 1085 512 1185 559
NOTES − The effect of static pressure and filter resistance is included in air volumes shown.
1st stage HEAT is approximately 91% of the same 2nd stage HEAT speed position.
1st stage COOL (two speed air conditioning units only) is approximately 70% (60% for units built prior to 09−2002) of the same 2nd stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same 2nd stage COOL speed position.
Lennox Harmony II zone control applications − Minimum blower heating speed is approximately 75% of the 1st stage HEAT speed position.
Lennox Harmony II zone control applications − Minimum blower cooling speed is approximately 42% of the 2nd stage COOL speed position.
G60UHV−60C−110 BLOWER PERFORMANCE
0 through 0.80 in. w.g. (0 Through 200 Pa) External Static Pressure Range
Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Return Air from Both Sides or
Return Air from Bottom and One Side.
Blower Control Factory Settings ADJUST − NORM
HEAT − 2
COOL − 4
ADJUST"
Switch
Positions
Speed Switch Positions
2nd Stage HEAT" Speed 2nd Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1485 700 1695 800 1910 900 2130 1005 1630 770 1750 825 1980 935 2185 1030
NORM (Normal) 1350 635 1540 730 1735 820 1935 915 1480 700 1590 750 1800 850 1985 940
" (Minus) 1215 575 1390 655 1560 735 1740 820 1335 630 1435 675 1620 765 1790 845
ADJUST"
Switch
Positions
1st Stage HEAT" Speed 1st Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1365 645 1550 730 1735 820 1925 910 1080 509 1075 507 1315 620 1445 681
NORM (Normal) 1240 585 1410 665 1575 745 1750 825 990 467 1050 495 1195 563 1315 620
" (Minus) 1115 525 1270 600 1420 670 1575 745 890 419 940 443 1075 507 1195 563
NOTES − The effect of static pressure and filter resistance is included in air volumes shown.
1st stage HEAT is approximately 91% of the same 2nd stage HEAT speed position.
1st stage COOL (two speed air conditioning units only) is approximately 70% (60% for units built prior to 09−2002) of the same 2nd stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same 2nd stage COOL speed position.
Lennox Harmony II zone control applications − Minimum blower heating speed is approximately 75% of the 1st stage HEAT speed position.
Lennox Harmony II zone control applications − Minimum blower cooling speed is approximately 42% of the 2nd stage COOL speed position.
