BLOWER DATA
G60UHV−60C−110 BLOWER PERFORMANCE
0 through 0.80 in. w.g. (0 Through 200 Pa) External Static Pressure Range
Single Side Return Air − Air volumes in bold require field fabricated transition to accommodate 20 x 25 x 1 in. (508 x 635 x 25 mm) clean-
able air filter in order to maintain proper air velocity across the filter.
Blower Control Factory Settings ADJUST − NORM
HEAT − 2
COOL − 4
ADJUST"
Switch
Positions
Speed Switch Positions
2nd Stage HEAT" Speed 2nd Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1430 675 1615 765 1835 865 2040 965 1530 720 1660 785 1875 885 2100 990
NORM (Normal) 1300 615 1470 695 1665 785 1855 875 1390 655 1510 715 1705 805 1910 900
" (Minus) 1170 550 1325 625 1500 710 1670 790 1250 590 1360 640 1535 725 1720 810
ADJUST"
Switch
Positions
1st Stage HEAT" Speed 1st Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1305 615 1480 700 1680 790 1865 880 965 455 1060 500 1205 568 1345 634
NORM (Normal) 1185 560 1345 635 1525 720 1695 800 885 417 965 455 995 469 1225 578
" (Minus) 1065 505 1210 570 1375 650 1525 720 795 375 875 412 985 464 1115 526
NOTES − The effect of static pressure and filter resistance is included in air volumes shown.
1st stage HEAT is approximately 91% of the same 2nd stage HEAT speed position.
1st stage COOL (two speed air conditioning units only) is approximately 70% (60% for units built prior to 09−2002) of the same 2nd stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same 2nd stage COOL speed position.
Lennox Harmony II zone control applications − Minimum blower heating speed is approximately 75% of the 1st stage HEAT speed position.
Lennox Harmony II zone control applications − Minimum blower cooling speed is approximately 42% of the 2nd stage COOL speed position.
G60UHV−60D−135 BLOWER PERFORMANCE
0 through 0.80 in. w.g. (0 Through 200 Pa) External Static Pressure Range
Bottom Return Air, Side Return Air with Optional RAB Return Air Base, Return Air from Both Sides or
Return Air from Bottom and One Side.
Blower Control Factory Settings ADJUST − NORM
HEAT − 2
COOL − 4
ADJUST"
Switch
Positions
Speed Switch Positions
2nd Stage HEAT" Speed 2nd Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1520 715 1725 815 1940 915 2130 1005 1630 770 1760 830 1985 935 2200 1040
NORM (Normal) 1385 655 1570 740 1765 835 1940 915 1480 700 1600 755 1805 850 2000 945
" (Minus) N/A N/A 1410 665 1590 750 1745 825 1335 630 1440 680 1625 765 1800 850
ADJUST"
Switch
Positions
1st Stage HEAT" Speed 1st Stage COOL" Speed
1 2 3 4 1 2 3 4
cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s cfm L/s
+" (Plus) 1395 660 1580 745 1760 830 1960 925 1090 514 1170 552 1315 620 1450 684
NORM (Normal) 1265 595 1435 675 1600 755 1785 840 995 469 1060 500 1200 566 1320 622
" (Minus) N/A N/A 1295 610 1440 680 1605 755 895 422 950 448 1080 509 1200 566
NOTES − The effect of static pressure and filter resistance is included in air volumes shown.
1st stage HEAT is approximately 91% of the same 2nd stage HEAT speed position.
1st stage COOL (two speed air conditioning units only) is approximately 70% (65% for units built prior to 09−2009) of the same 2nd stage COOL speed position.
Continuous Fan Only speed is approximately 38% of the same 2nd stage COOL speed position.
Lennox Harmony II zone control applications − Minimum blower heating speed is approximately 75% of the 1st stage HEAT speed position.
Lennox Harmony II zone control applications − Minimum blower cooling speed is approximately 45% of the 2nd stage COOL speed position.
N/A − 1st stage HEAT, speed position 1 with " (Minus) Adjust" setting, cannot be used with this model.
