Lennox GAH 020S

• 29 •
GAC/GAH 020S-025S
SPXX WTNG
DPXX WFIF
AVUB
GAC-H_020S_025S_Z
GAC-H_020S_025S_S_H_Z
Installation manual /eCOMFORT-MIL150E-0916 / 05/2017
Controller
connection
Ø 29
Controller
connection
Ø 29
All dimensions in mm
All dimensions in mm
1.- GENERAL CHARACTERISTICS
1.9.- DIMENSIONS
STANDARD VERSION
UNIT WITH STANDARD EC FANS (SEAS) OR HIGH PRESSURE EC FANS (HIPF)
3
meters
1
meter
1
meter
1
meter
3
meters
1
meter
1
meter
1
meter
Hydraulic module with single pump Water tank
Hydraulic module with twin pum Water fi lter (supplied loose)
Rubber anti-vibration mounts
1 1/2”
Threaded
male
1 1/2”
Threaded male
1 1/2”
Threaded female
1 1/2”
Threaded
male
1 1/2”
Threaded male
1 1/2”
Threaded female
