Page 18
THERMISTOR LOCATION RT42 & 46
036 & 048 THREE-ROW EVAPORATOR COIL
(VIEW FROM FRONT SIDE OF UNIT)
RT42
RT46
TOR TUBE
CLAMP THERMISTOR
TO BARE COPPER;
TOR SLEEVE
SUCTION
LINE
TXV BULB
DETAILS NOT TO SCALE
FIGURE 6
