Page 19
THERMISTOR LOCATION RT42 & 46
060U & 074 FOUR-ROW EVAPORATOR COIL
(VIEW FROM FRONT SIDE OF UNIT)
RT42
RT46
DISTRIBUTOR
TUBE
CLAMP THERMISTOR TO
BARE COPPER; NOT THE
DISTRIBUTOR SLEEVE
SUCTION LINE
TXV BULB
DETAILS NOT TO SCALE
FIGURE 7
