Technical Information
Service Manual
2.4 Cooling and Heating Data Sheet in Rated Frequency
Instruction:
T1: Inlet and outlet pipe temperature of evaporator
T2: Inlet and outlet pipe temperature of condenser
P: Pressure at the side of big valve
Connection pipe length: 7.5 m.
Cooling:
Heating:
Rated cooling
condition(
) (DB/WB)
Model
Pressure of gas pipe
connecting indoor
and outdoor unit
Inlet and outlet pipe
temperature of heat
exchanger
Fan speed
of indoor
unit
Fan speed
of outdoor
unit
Compressor
revolution (rps)
Indoor Outdoor P (MPa) T1 (
) T2 (
)
27/19 35/24 LNINVE052/LNINVC052 0.9~1.1
in:8~9
out:10~12
in:75~85
out:37~43
Super High High 68
27/19 35/24 LNINVE063/LNINVC063 0.9~1.1
in:7~9
out:10~12
in:75~85
out:37~43
Super High High 73
27/19 35/24 LNINVE070/LNINVC070 0.9~1.1
in:8~9
out:10~12
in:75~85
out:37~43
Super High High 52
27/19 35/24 LNINVE080/LNINVC080 0.9~1.1
in:7~9
out:10~12
in:75~85
out:37~43
Super High High 58
Rated cooling
condition(
) (DB/WB)
Model
Pressure of gas pipe
connecting indoor and
outdoor unit
Inlet and outlet pipe
temperature of heat
exchanger
Fan speed
of indoor
unit
Fan speed
of outdoor
unit
Compressor
revolution (rps)
Indoor
Outdoor P (MPa)
T1 (°C)
T2 (°C)
20/15
7/6 LNINVE052/LNINVC052
2.2~2.4
in:75~85
out:37~43
in:1~3
out:2~5
Super High High
72
20/15 7/6 LNINVE063/LNINVC063 2.2~2.4
in:75~85
out:37~43
in:1~3
out:2~5
Super High High 77
20/15 7/6 LNINVE070/LNINVC070 2.2~2.4
in:75~85
out:37~43
in:1~3
out:2~5
Super High High 56
20/15 7/6 LNINVE080/LNINVC080 2.2~2.4
in:75~85
out:37~43
in:1~3
out:2~5
Super High High 89
