Outdoor Unit
Model of Outdoor Unit LNINVC052 LNINVC063
Compressor Manufacturer/Trademark
MISUBISHI ELECTRIC/MITSUBISHI
ELECTRIC(GUANGZHOU)
COMPRESSOR CO., LTD
MISUBISHI ELECTRIC/MITSUBISHI
ELECTRIC(GUANGZHOU)
COMPRESSOR CO., LTD
Compressor Model SNB130FGYMC SNB130FGYMC-L1
Compressor Oil FV50S FV50S
Compressor Type Rotary Rotary
L.R.A. A 27 27
Compressor RLA A 8.4 8.4
Compressor Power Input W 1245±5% 1245±5%
Overload Protector INTILL-6578 1NT11L-6578
Throttling Method Capillary Capillary
Operation temp
O
C 16~30 16~30
Ambient temp (Cooling)
O
C 18~43 18~43
Ambient temp (Heating)
O
C -7~24 -7~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ9.52 Φ9.52
Rows-n Gap mm 1-1.4 2-1.4
Coil Length (LXWXD) mm 853X22X660 847X44X660
Fan Motor Speed rpm 700 780
Output of Fan Motor W 60 60
Fan Motor RLA A 0.28 0.28
Fan Motor Capacitor μF / /
Air Flow Volume of Outdoor Unit m
3
/h 3200 3200
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ520 Φ520
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IP24 IP24
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5 2.5
Sound Pressure Level (H) dB (A) 54 56
Sound Power Level (H) dB (A) 64 66
Dimension (WXHXD) mm 955X700X396 955X700X396
Dimension of Carton Box (LXWXH) mm 1026X455X735 1026X455X735
Dimension of Package (LXWXH) mm 1029X458X750 1029X458X750
Net Weight kg 44 50
Gross Weight kg 49 55
Refrigerant R410A R410A
Refrigerant Charge kg 1.2 1.9
Connection
Pipe
Length m 7.5 7.5
Gas Additional Charge g/m 20 50
Outer Diameter Liquid Pipe mm Φ6 Φ6
Outer Diameter Gas Pipe mm Φ12 Φ16
Max Distance Height m 10 10
Max Distance Length m 25 25
Note: The connection pipe applies metric diameter.
