5
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit LNINVC070
Compressor Manufacturer/Trademark
MITSUBISHI ELECTRIC(GUANGZHOU) COMPRESSOR
CO.,LTD/MITSUBISHI ELECTRIC
Compressor Model TNB220FLHMC
Compressor Oil PV50S
Compressor Type Rotary
L.R.A. A 45.00
Compressor RLA A 9.70
Compressor Power Input W 2200
Overload Protector CS-7C-1595
Throttling Method Capillary
Operation temp
O
C 16~30
Ambient temp (Cooling)
O
C 18~43
Ambient temp (Heating)
O
C -7~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Rows-n Gap mm 2-1.4
Coil Length (LXWXD) mm 953X38.1X748
Fan Motor Speed rpm 780/500
Output of Fan Motor W 90
Fan Motor RLA A 0.79
Fan Motor Capacitor μF 7
Air Flow Volume of Outdoor Unit m
3
/h 4000
Fan Type Axial-ow
Fan Diameter mm Φ552
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 3.8
Permissible Excessive Operating
Pressure for the Suction Side
MPa 1.2
Sound Pressure Level (H) dB (A) 59
Sound Power Level (H) dB (A) 69
Dimension (WXHXD) mm 980X790X427
Dimension of Carton Box (LXWXH) mm 1080X485X840
Dimension of Package (LXWXH) mm 1083X488X855
Net Weight kg 65
Gross Weight kg 73
Refrigerant R410A
Refrigerant Charge kg 1.80
Connection
Pipe
Length m 7.5
Gas Additional Charge g/m 30
Outer Diameter Liquid Pipe mm Φ6
Outer Diameter Gas Pipe mm Φ16
Max Distance Height m 10
Max Distance Length m 30
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
