Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
LNINVE052
Product Code CB162N07700_K96357
1 Front Panel Assy 20012286 1
2 Filter Sub-Assy 1112208901 2
3 Screw Cover 24252016 3
4 Bafe Plate 26112228 1
5 Front Case Sub-assy 20022172 1
6 Air Louver 1 10512116 1
7 Air Louver 2 10512117 1
8 Helicoid Tongue 26112238 1
9 Left Axile Bush 10512037 1
10 Rear Case assy 12312214 1
11 Rubber Plug (Water Tray) 76712012 1
12 Ring of Bearing 26152022 1
13 O-Gasket sub-assy of Bearing 7651205102 1
14 Cross Flow Fan 10352019 1
15 Evaporator Support 24212133 1
16 Evaporator Assy 01002575 1
17 Wall Mounting Frame 01252218 1
18 Motor Press Plate 26112494 1
19 Fan Motor 15012146 1
20 Pipe Clamp 26112164 1
21 Drainage Hose 05230014 1
22 Step Motor 15012086 1
23 Crank 10582070 1
24 Display Board 30565093 1
25 Guide Louver 10512115 1
26 Axile Bush 10542036 1
27 Electric Box 2011210801 1
28 Terminal Board 4201026601 1
29 Electric Box Cover2 20112081 1
30 Main Board 30138736 1
31 Lower Shield of Electric Box 01592091 1
32 Electric Box Cover1 20122154 1
33 Jumper 4202300102 1
34 Capacitor CBB61 33010043 1
35 Electric Box Assy 20102000020 1
36 Connecting Cable 400205235 0
37 Temperature Sensor 390000453 1
38 Ambient Temperature Sensor 390000453 1
39 Remote Controller 305100413 1
Above data is subject to change without notice.
