80
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
QtyLNINVE063
Product Code CB162N07800_K96357
1 Front Panel Assy 20012368 1
2 Filter Sub-Assy 11122091 2
3 Screw Cover 24252016 3
4 Front Case Assy 20012329 1
5 Air Louver1 10512159 3
6 Helicoid Tongue 26112187 1
7 Left Axile Bush 10512037 1
8 Rear Caseassy 2220211706 1
9 Rubber Plug(Water Tray) 76712012 1
10 Ringof Bearing 26152025 1
11 O-Gasket sub-assy of Bearing 76512203 1
12 Cross Flow Fan 10352045 1
13 Evaporator Support 24212103 1
14 Evaporator Assy 0100257204 1
15 Wall Mounting Frame 01252032 1
16 Motor Press Plate 26112316 1
17 Fan Motor 15012098 1
18 Pipe Clamp 26112188 1
19 Drainage Hose 0523001405 1
20 Step Motor 1521300101 1
21 Axile Bush 10542036 2
22 Display Board 30565041 1
23 Guide Louver 10512118 1
24 Crank 10582070 1
25 Electric Box 2011210801 1
26 Terminal Board 4201026601 1
27 Electric Box Cover2 20112081 1
28 Main Board 30138737 1
29 Shield Cover of Electric Box 01592092 1
30 Electric Box Cover1 20122154 1
31 Jumper 4202300107 1
32 Capacitor CBB61 33010034 1
33 Electric Box Assy 20102000031 1
34 Connecting Cable 400205235 0
35 Connecting Cable 400205235 0
36 Temperature Sensor 390000453 1
37 Ambient Temperature Sensor 390000591 1
38 Remote Controller 305100413 1
