82
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
LNINVE070 LNINVE080
Product Code CB162N03700_K96357 CB162N07600_K96357
1 Front Panel 20012682 20012682 1
2 Filter Sub-Assy 11122112 11122112 2
3 Front Case 2000237002 2000237002 1
4 Front Case Sub-assy 2000257202 2000257202 1
5 Upper Guide Louver 10512062 10512062 1
6 Lower Guide Louver 10512063 10512063 1
7 Connecting Rod of Swing Louver 10582040 10582040 3
8 Air Louver 10512484 10512484 15
9 Water Tray 20182043 20182043 1
10 Screw Cover 242520053 242520053 3
11 Rubber Plug (Water Tray) 76712012 76712012 1
12 Rear Case Sub-Assy 22202092 22202092 1
13 Cross Flow Fan 10352420 10352420 1
14 O-Gasket sub-assy of Bearing 76512051 76512051 1
15 Axile Bush 10542704 10542704 6
16 Left Evaporator Support 24212041 24212041 1
17 Evaporator Assy 01002924 1002924 1
18 Fixed Clip (Evaporator) 02112009 02112009 1
19 Wall Mounting Frame 01252398 01252398 1
20 Fan Motor 1501212004 15012120 1
21 Right Support of Evaporator 2421204201 2421204201 1
22 Pipe Clamp 26112071 26112071 1
23 Drainage Hose 0523001403 0523001403 1
24 Motor Fixed Clip 26112069 26112069 1
25 Step Motor 1521210701 1521210701 1
26 Press Plate(Crank) 26112070 26112070 1
27 Crank-guide 10582041 10582041 1
28 Lower crank 10562005 10562005 1
29 Upper Crank 10562004 10562004 1
30 Electric Box Assy 20302961 20302961 1
31 Electric Box 201022501 201022501 1
32 Capacitor CBB61 33010737 33010737 1
33 Terminal Board 42011233 42011233 1
34 Main Board 30138795 30138795 1
35 Display Board 30565099 30565044 1
36 Electric Box Cover 20102252 20102252 1
37 Electric Box Cover 2011204402S 2011204402S 1
38 Remote Controller 305100413 305100413 1
39 Connecting Cable 40020318 400205408 0
40 Connecting Cable 4002052313 400204056 0
41 Temp Sensor Sleeving 390000451 390000451 1
42 Ambient Temperature Sensor 390000591 390000591 1
To Next Page
