Lennox LNINVC063 User Manual

84
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
LNINVC052 LNINVC063
Product Code CB161W03100_K96357 CB161W03200_K96357
1 Front Grill 22415002 22415002 1
2 Front Panel 01535008P 01535008P 1
3 Drainage Plug 06813401 06813401 3
4 Drainage Connecter 06123401 06123401 1
5 Chassis Sub-assy 0120386502P 0120386502P 1
6 Capacitor Clamp Sub-assy 01413098 01413098 1
7 Capacitor CBB65 33000065 33000065 1
8 Compressor and ttings 00205262 00103807 1
9 Rubber Grommet 76815215 76815215 3
10 4-Way Valve Assy 03123667 03123661 1
11 Right Side Plate 01305053P 01305053P 1
12 Valve support assy 01715010P 01713087P 1
13 Cut off Valve 071302392 07133157 1
14 Cut off Valve Sub-Assy 07133464 07133476 1
15 Handle 26235254 26235254 1
16 Electric Box Assy 0260356807 0260356808 1
17 Insulated Board (Cover of Electric Box) 20113003 20113003 1
18 Electric Box (Fireproong) 01413148 01413148 1
19 Magnet Coil 4300040033 4300040033 1
20 Capillary Sub-assy 03063561 03063561 1
21 Temperature Sensor 3900030901 3900030901 1
22 Wiring clamp 26115004 26115004 1
23 Rear Grill 01473043 01473043 1
24 Condenser Assy 01163080 01163080 1
25 Top Cover 01255005P 01255005P 1
26 Condenser support plate 01795010 01795010 1
27 Clapboard Sub-Assy 01232902 01232902 1
28 Motor Support Sub-Assy 0170502003 0170502003 1
29 Left Handle 26235401 26235401 1
30 Reactor 43130021 43130021 1
31 Fan Motor 15015064 15015064 1
32 Left Side Plate 01305041P 01305041P 1
33 Axial Flow Fan 10335008 10335008 1
