Lennox LNINVC063 User Manual

86
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
LNINVC070 LNINVC080
Product Code CB171W04400_K96357 CB161W03300_K96357
1 Front Grill 22415003 22415003 1
2 Cabinet 01435004P 01435004P 1
3 Left Handle 26235401 26235401 2
4 Front Side Plate 01305086P 01305086P 1
5 Chassis Sub-assy 0120509701P 0120509702P 1
6 Drainage Connecter 06123401 06123401 1
7 Drainage Plug 06813401 06813401 3
8 Compressor and Fittings 00105036 00105036 1
9 Reactor 43130183 43130183 1
10 Electric Box Assy 02603522 0260352201 1
11 Electric Box (Fireproong) 01413426 01413426 1
12 4-Way Valve Assy 03025297 03123725 1
13 Right Side Plate 01305044P 01305044P 1
14 Valve Support Sub-Assy 01715020P 01715020P 1
15 Cut off Valve Sub-Assy 07135054 07133232 1
16 Cut off Valve 07130239 07130239 1
17 Cut off Valve 07133157 07133157 1
18 Big Handle 26235001 26235001 1
19 Capacitor Clamp 02141375 02141375 2
20 Capacitor CBB65 33000039 33000039 2
21 Magnet Coil 4300040033 4300040033 1
22 Capillary Sub-assy 0300551505 03063803 1
23 Temp Sensor Sleeving 05212423 05212423 1
24 Wiring Clamp 26115004 26115004 1
25 Rear Grill 01475013 01475013 1
26 Condenser Assy 01113922 01163314 1
27 Condenser Support Plate 01175092 01175092 1
28 Top Cover 01255006P 01255006P 1
29 Clapboard Assy 01235034 01233138 1
30 Motor Support Sub-Assy 01705025 01705437 1
31 Fan Motor 1501506204 1501506204 1
32 Left Side Plate 01305043P 01305043P 1
33 Axial Flow Fan 10335005 10335005 1
Above data is subject to change without notice.
