Page 106
Table 64. M3 Control Parameters
Control Parameter
DescriptionUnits
Control Value
No DescriptionUnitsMax.DefaultMin.Parameter Short DescriptionScreen Name
41 BLOWER MANUAL RESET
Constant Air Volume with
Bypass Damper Manual Reset
Value Output Percentage
Setpoint
20.0 52.0 100.0 %
Constant air volume with bypass damper manual reset value output.
This is the output when unit is off.
42 STATIC SHUTDOWN SP
Air Supply Static Shutdown
Setpoint
0 2 5 w.c.
Supply static shutdown set point. Unit will shutdown for Parameter
110 minutes if duct pressure exceeds this value for 20 seconds.
43 STATIC LOCKOUT CNT
Static Pressure Lockout
Counter Setpoint
1 3 7 Counts
The number of occurrences before permanent lockout. Counter
resets when M3 resets.
Refer to Parameter 226 to either enable or disable this feature.
44 STATIC LO ALARM CHK
Supply Static Sensor (A30) Low
Alarm Percentage Setpoint
30.0 40.0 100.0 %
Supply Static Pressure Sensor (A30) connected at
(A133_P195_6) (TB18_6) alarm threshold.
Blower percent speed before checking sensor after a 20 second
delay.
A value of 30% disables the low threshold or “open" alarm trap.
Electric Heating Parameters
58 HT ELEC WARMUP DLAY
Electric Heat Warm-up Time
Delay for Economizer
0 3584 8160 Seconds
Warm-up time delay. The time that the economizer is forced closed
during warm-up (first occupied + heat demand)
59 HT ELEC BLR ON DLAY
Electric Heat Blower On Delay
Setpoint.
0 0 0 Seconds The time before the blower turns on after a electric heating demand.
60 HT ELEC BL OFF DLAY
Electric Heat Blower Off Delay
Setpoint.
0 20 300 Secs The time the blower stays on after the heating demand is lost.
61 HT ELEC MAX LT OCC
Electric Heat Maximum Primary
and Secondary
1 3 15 Counts
Service output activation. Maximum Primary and Secondary Limit
occurrences stored before service relay is energized.
Note: Heating stage is not locked out.
62 HT ELEC STAGE DELAY
Electric Heat Time Delay
Between Heat Stages
12 12 60 Seconds Time delay between heat stages.
63 HT ELEC STG UP TMR
Electric Heat Maximum Lower
Stage Run Time in Room
Sensor Applications
0 912 3600 Seconds
Stage up timer. The maximum time that lower stage runs before
calling next heat stage. Used in room sensor applications.
Disabled if set to 0.
64 HT ELEC STG DWN TMR
Electric Heat Time Delay for
Lower Stage Termination
Following Higher Stage
Termination
0 0 3600 Seconds
Time delay before a lower stage turns off following a higher stage
termination.
Used in room sensor applications.
Gas Heating Parameters
65 HT GAS WARMUP DELAY
Gas Time Delay for Economizer
Being Closed During Warm-up
0 3584 8160 Seconds
Warm-up time delay. The time that the economizer is forced closed
during warm-up (first occupied + heat demand) .
66 HT GAS BLR ON DELAY
Gas Blower On Delay After
Heating Demand
8 40 60 Seconds The time before the blower turns on after a heating demand.
67 HT GAS BLR OFF DLAY
Gas Blower Off Delay After
Heading Demand Termination
80 120 300 Seconds The time the blower stays on after the heating demand is terminated.
