Page 126
Table 65. M2 ECTO to M3 Parameter Cross-Reference
ECTO
Accessible via
Settings Menu
M3 Parameter NameM3 Parameter
5.18 119 DIN_DCV_Damper_Full_Open_SP Y
5.19 122 DIN_DCV_Low_Temp_Override_Full_Closed Y
5.20 123 DIN_DCV_Low_Temp_Override_Start_Closing Y
5.21 121 DIN_DCV_High_Temp_Override_Start_Closing Y
5.22 120 DIN_DCV_High_Temp_Override_Full_Closed Y
5.23 131 DIN_Free_CL_Max_Damper Y
5.24 132 DIN_Min_Damper_Position Y
5.25 133 DIN_Zone_Sensor_StartUp_Delay Y
5.26 134 DIN_IAQ_Input_Mode Y
5.27 NONE
6.01 136 DIN_SystemMode N
6.02 137 DIN_BackupOcc_HT_SP Y
6.03 138 DIN_BackupUnOcc_HT_SP Y
6.04 139 DIN_BackupOcc_CL_SP Y
6.05 140 DIN_BackupUnOcc_CL_SP Y
6.06 141 DIN_AfterHoursOverrideTimeDelay Y
6.07 142 DIN_HT_StageDeadband Y
6.08 143 DIN_CL_StageDeadband Y
6.09 148 DIN_HT_Stage1StageDifferential Y
6.10 144 DIN_CL_Stage1StageDifferential Y
6.11 149 DIN_HT_Stage2StageDifferential Y
6.12 145 DIN_CL_Stage2StageDifferential Y
6.13 146 DIN_CL_Stage3StageDifferential Y
6.14 147 DIN_CL_Stage4StageDifferential Y
6.15 152 DIN_MinAutoChangeoverDeadband Y
6.16 153 DIN_AutoChangeOverTimeDelay Y
6.17 154 DIN_Blower_Control Y
6.18 NONE
6.19 155 DIN_FreeCooling_Lockout_SP Y
6.20 156 DIN_FAH_SP Y
6.21 157 DIN_FAH_StageDeadband Y
6.22 158 DIN_FAH_MinCycleTime Y
6.23 159 DIN_Free_Cooling_Supply_SP Y
6.24 150 DIN_HT_Stage3StageDifferential Y
6.25 151 DIN_HT_Stage4StageDifferential Y
6.26 160 DIN_Economizer_Free_Cooling_Temp_SP Y
6.27 164 DIN_EconomizerProfile Y
7.01 165 DIN_FAH_StageDifferential Y
7.02 166 DIN_FAH_Reheat_OAT_SP Y
7.03 167 DIN_FAH_Reheat_Damper Y
7.04 168 DIN_FAH_Reheat_SP Y
7.05 169 DIN_FAT_AutoChangeOverDelay Y
7.06 170 DIN_FAC_SP Y
