Page 127
Table 65. M2 ECTO to M3 Parameter Cross-Reference
ECTO
Accessible via
Settings Menu
M3 Parameter NameM3 Parameter
7.07 171 DIN_FAC_StageDeadband Y
7.08 172 DIN_FAC_MinCycleTime Y
7.09 173 DIN_FAC_StageDifferential Y
7.10 174 DIN_DACH_OCP_SP Y
7.11 175 DIN_DACH_UnOCP_SP Y
7.12 176 DIN_DACH_StageDeadband Y
7.13 177 DIN_DACH_FAH_StageUpTimer Y
7.14 178 DIN_DACH_FAH_StageDownTimer Y
7.15 179 DIN_DACH_StageDifferential Y
7.16 180 DIN_DACC_OCP_SP Y
7.17 181 DIN_DACC_UnOCP_SP Y
7.18 182 DIN_DACC_StageDeadband Y
7.19 183 DIN_DACC_FAC_StageUpTimer Y
7.20 184 DIN_DACC_FAC_StageDownTimer Y
7.21 185 DIN_DACC_StageDifferential Y
7.22 186 DIN_Service_Output_Control_Mode Y
7.23 187 DIN_Service_Output_SP_CO2 Y
7.24 190 DIN_Service_Output_DB_CO2 Y
7.25 194 DIN_Load_Shed_Option Y
7.26 196 DIN_BACnet_MAC_Address Y
8.01 207 DIN_DACC_RS_Limit Y
8.02 205 DIN_DACC_RAT_RS_SP Y
8.03 206 DIN_DACC_RAT_RS_Proportional_Band Y
8.04 204 DIN_DACC_RAT_RS_Adjust_Band Y
8.04 211 DIN_DACH_RAT_RS_Adjust_Band Y
8.05 202 DIN_DACC_OAT_RS_SP Y
8.06 203 DIN_DACC_OAT_RS_Proportional_Band Y
8.07 201 DIN_DACC_OAT_RS_Adjust_Band Y
8.08 214 DIN_DACH_RS_Limit Y
8.09 212 DIN_DACH_RAT_RS_SP Y
8.10 213 DIN_DACH_RAT_RS_Proportional_Band Y
8.12 209 DIN_DACH_OAT_RS_SP Y
8.13 210 DIN_DACH_OAT_RS_Proportional_Band Y
8.14 208 DIN_DACH_OAT_RS_Adjust_Band Y
8.15 NONE
8.16 NONE
8.17 NONE
8.18 NONE
8.19 NONE
8.20 215 DIN_Exh_Fan_Stage1_Damper_SP Y
8.21 216 DIN_Exh_Fan_Stage1_Damper_DB Y
8.22 224 DIN_Exh_Fan_StageDown_Delay Y
8.23 219 DIN_Exh_Fan_Stage2_Damper_SP Y
