Lennox PRODIGY2.0 User Manual

127
Table 63. M3 Control Parameters
Control Parameter
DescriptionUnits
Control Value
No DescriptionUnitsMax.DefaultMin.
Parameter Short
Description
Screen Name
164
ECONOMIZER
PROFILE
Economizer Profile 0 2 3 Option
These are the operating profile
options for the economizer
damper during free cooling
when any compressor is on and
can be selected as follows:
Option 0: Damper continues to
modulate while compressors
are on, but the effect of mech
anical cooling may force the
damper closed to its minimum
position. After compressor
starts, the free cooling setpoint
is lowered to a fixed temperat
ure of 45°F.
Option 1: Damper opens to its
maxopen position (parameter
131 - FREE CL MAX DAMPER)
when any compressors start.
NOTE: When using Option 1
and after the compressor is
stopped, the M3 shall resume
damper modulation.
Option 2: Damper continues to
modulate while compressors
are on, but the effect of mech
anical cooling may force the
damper closed to its minimum
position. This is the factory de
fault setting.
 Holdsoff compressor on Y2
call until damper has modu
lated to maximum position
(parameter 131 - FREE CL
MAX DAMPER) for three
minutes.
 After three minutes, com
pressor starts and the free
cooling setpoint is lowered to
45°F. Damper is not locked
at maximum open while
compressor is on, but modu
lates to maintain 45°F dis
charge air temperature.
 When Y2 is satisfied, com
pressor goes off and free
cooling setpoint is restored
to 55°F (parameter 159 -
FREE COOL SUPPLY SP).
Option 3: Same as Option 2,
but with a 10 minute delay in
stead of a three minute delay.
System 2 Parameters
165 FAH STAGE DIFFER
Fresh Air Heating Stage
Differential
0.0 2.0 20.0 °F
 Fresh Air Heating stage dif
ferential.
 0 value for first stage heating
only for Fresh Air Heating.
166 FAH REHEAT OAT SP
Fresh Air Heating
Control Reheat Outdoor
Air Temperature Set
Point
20.0 45.0 60.0 °F
Outdoor air temperature set
point that enables fresh air
heating for reheat demand and
opens damper to parameter 167
when outdoor air is less than
set point.
