Lennox PRODIGY2.0 User Manual

160
Table 70. P265 Contactors / Relays
Pin # Label Description Type
1 COM 24VAC COMMON 24VAC COM
2 K1 CONTACTOR COMPRESSOR 1 24VAC DO
3 K2 CONTACTOR COMPRESSOR 2 24VAC DO
4 K3 CONTACTOR BLOWER 24VAC DO
*
ENERGENCE STANDARD EFFICIENCY 3 TO 6-TON UNITS INDOOR BLOWER
LOW
24VAC DO
5 COM 24VAC COMMON 24VAC COM
6 K10 RELAY OUTDOOR FAN 1 24VAC DO
* RELAY K191 ULTRA: CRANKCASE HEATER 24VAC DO
7 K68 RELAY OUTDOOR FAN 2 24VAC DO
* A-BOX: INDOOR BLOWER HIGH 24VAC DO
* RELAY K196 ULTRA: CRANKCASE HEATER 24VAC DO
8 COM 24VAC COMMON 24VAC COM
9 K13 RELAY COMBUSTION AIR BLOWER 1 24VAC DO
10 COM 24VAC COMMON 24VAC COM
11 K85 RELAY EXHAUST FAN 24VAC DO
Table 71. P266 Heating Control and Damper ΔP Sensor
Pin # Label Description Type
1 COM 24VAC COMM 24VAC COM
2 A3, K15 HEAT 1, ELECTRIC HEAT 1 24VAC DO
3 W2, K16 HEAT 2, ELECTRIC HEAT 2 24VAC DO
4 DDPS DAMPER DIFFER. PRESSURE SENSOR 0-5VDC
5 GND GROUND GND
6 5VDC 5VDC SUPPLY 5VDC
Table 72. P267 Outdoor Fan Area
Pin # Label Description Type
1 RT17 OUTDOOR AIR TEMP
RES 0-5VDC
2 GND DIGITAL GROUND
3 S11 LOW PRESSURE FAN 1 SW 24VAC
4 R 24VAC 24VAC DO
5 S84 LOW PRESSURE FAN 2 SW 24VAC
6 A30 STATIC DUCT PRESSURE 10VDC
7 GND GROUND GND
8 5VDC 5VDC SUPPLY 5VDC
Table 73. P268 Power
Pin # Label Description Type
1 T1-1 24VAC POWER TRANSFORMER 1 24VAC
2 T1-COM 24VAC COMMON TRANSFORMER 1 24VAC COM
3 T18-1 24VAC POWER TRANSFORMER 1 24VAC
4 T18-COM 24VAC COMMON TRANSFORMER 1 24VAC COM
Table 74. P269 Reheat - Humiditrol: Ultra - TXV
Pin # Label Description Type
1 T43 24VAC POWER 24VAC
2 T43 24VAC COMMON 24VAC COM
3 L14 REHEAT SOLENOID 1: ULTRA TXV 1 24VAC DO
4 L30 REHEAT SOLENOID 2: ULTRA TXV 2 24VAC DO
5 RSV RESERVED 24VAC DI
