Page 4
XC21
Unit Dimensions − Inches (mm) and Parts Arrangement
39−1/2
(1003)
35−1/2
(902)
47
(1194)
18−1/2
(470)
8 (203)
1 (25)
4−1/2
(114)
LIQUID
LINE
INLET
ELECTRICAL
INLETS
SIDE VIEW
ACCESS VIEW
DISCHARGE
AIR
4−5/8
(117)
BASE WITH ELONGATED LEGS
16−7/8
(429)
8−3/4
(222)
26−7/8
(683)
3−3/4 (95)
30−3/4
(781)
3−1/8
(79)
SUCTION
LINE
INLET
UNIT SUPPORT
FEET

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lennox XC21 Series and is the answer not in the manual?

Lennox XC21 Series Specifications

General IconGeneral
SEER RatingUp to 21.00
Sound RatingAs low as 69 dB
Energy Star CertifiedYes
RefrigerantR-410A
Cooling Capacity2 to 5 tons
Warranty10-year limited warranty on compressor and covered components
