Applying labels to the bottom cover
The new bottom cover FRU is shipped with a kit containing labels of several kinds. Apply those labels when
you replace the bottom cover. For the labels that are not shipped with the new bottom cover, peel them off
from the old bottom cover, and adhere them to the new one.
The following illustration shows the location of each label for the computer models.
1 GEO label 2 Israel Homologation label/Indonesia Rating and Postel
label/Argentina CNC label
3 S/N label 4 CECP label
5 Argentina Electrical Safety Label
6 Brazil Anatel label
7 Genuine Microsoft label (Windows 10)
8 Asset tag label
9 IMEI label
10 Rating and information label
66 E490 and R490 Hardware Maintenance Manual
