Table 10. System board (continued)
Item
Connector (location)
Internal cable required
Cable connection
17
Thermal fan connector
(internal)
Thermal fan assembly
cable
The thermal fan assembly comes with cable.
Connect the cable to this connector.
18
Keyboard connector
(internal)
Keyboard cable
Connect one end to the keyboard and the other end
to this connector.
19
Trackpoint connector
(internal)
Trackpoint cable
Connect one end to the TrackPoint and the other end
to this connector.
Looking up FRU information
For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to:
http://www.lenovo.com/serviceparts-lookup
Chapter 6. Locations 55
