Lenovo Ideapad E490 - Page 78

For short M.2 solid-state drive
Note: If necessary, remove the short M.2 solid-state drive retainer.
Step Screw (quantity) Color
Torque
1
M2 × 2.5 mm, flat-head, nylon-coated (1) Silver 0.181 Nm
(1.85 kgf-cm)
For long M.2 solid-state drive
Note: If necessary, remove the long M.2 solid-state drive bracket.
Step Screw (quantity) Color
Torque
1
M2 × 3 mm, flat-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgf-cm)
Chapter 8. Removing or replacing a FRU 71
