Lenovo PHAB Plus Hardware Maintenance Manual
40
2. Remove screws at the positions shown in the figure below.
Figure 3-2. Removing the screws on the SIM board
3. Remove the SIM board.
Figure 3-3. Removing the SIM board
Part No. Screw (quantity) Color Torque
Phillips cross head screw, M1.4 × 2.38(3) Black N/A
