Lenovo PHAB Plus Hardware Maintenance Manual
56
3. Remove screws at the positions shown in the figure below.
Figure 10-3. The screws on the sub board
4. Pull out the sub board from the front module.
Figure 10-4. Removing the sub board
Part No. Screw (quantity) Color Torque
Phillips cross head screw, M1.4 × 2.38 (2) Black N/A
