Lenovo ThinkCentre Tiny-in-One 24 User Manual

Part 4: Install the Kensington-style cable lock (optional).
With the key of the Kensington-style cable lock, attach the lock to the security-lock slot on the rear panel of your
computer as shown. The lock secures your monitor to a desk, table, or other non-permanent fixture. It also locks the
3-in-1 cable so that the Tiny cannot be removed from the monitor.
Connecting cables
After assembling your monitor, you must connect cables correctly to use the monitor and computer. Your
monitor can be used with either the Tiny installed in the monitor or an external desktop computer. To connect
cables, do one of the following:
● If you use the Tiny installed in the monitor, connect the ac power adapter cable and power cord that comes
with the monitor. First connect the ac power adapter cable to the ac power adapter connector on the monitor.
Then, connect one end of the power cord to the ac power adapter and the other end to a properly-grounded
electrical outlet.
● If you use the external desktop computer, do the following:
1. Use a DisplayPort cable of this type as shown. Connect one end of the DisplayPort cable to the DisplayPort
connector on the monitor and the other end to a DisplayPort connector on the computer. To locate the
DisplayPort connector on the monitor, see “Locating connectors and controls on your monitor” on page 2.
6 ThinkCentre Tiny-in-One 24 User Guide

Lenovo ThinkCentre Tiny-in-One 24 Specifications

General

3D	No
Color gamut	72 %
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Display surface	Matt
Display diagonal	23.8 \
Native aspect ratio	16:9
Viewable size diagonal	604.7 mm
Viewable size, vertical	313 mm
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	535 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 350, 640 x 480 (VGA), 720 x 400, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1280 x 800, 1366 x 768, 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
On/off switch	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	35 W
Power consumption (typical)	16.7 W
Certification	China RoHS, China Energy Efficiency Standard Tier 1, RoHS EU, RoHS (Turkey), EPEAT Gold, Energy Star 7.0, RoHS Ukraine
Product color	Black
Market positioning	Business
RMS rated power	1.5 W
Number of speakers	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Tilt angle range	-5 - 35 °
Number of OSD languages	8
Panel mounting interface	100 x 100 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	251.4 mm
Height (with stand)	385.08 mm
Weight (with stand)	5570 g
Depth (without stand)	68.2 mm
Width (without stand)	539.6 mm
Height (without stand)	346.45 mm
Weight (without stand)	- g
