ThinkPadTablet2Dock
TheThinkPadTablet2Dock(hereaftercalledthedock)holdsyourtabletinanuprightpositionandfreesyour
handstodoothertasks.ItalsoprovidesyouwitheasyaccesstoconnectorsforUSBdevices,filetransfers,
charging,audioinput,audiooutput,andvideooutput.
Figure6.Dockfrontviewandrightsideview
1Dockconnector
Thisconnectorestablishestheconnectionbetweenthedockandtabletwhenyourtabletisseatedinthe
dock.
2USBconnector
ConnectUSBdevices,suchasaUSBkeyboardoraUSBstoragedevice.
Note:ThisconnectoriscompatiblewiththeUSB2.0standard.
Figure7.Dockrearview
1HDMIconnector
Connectacompatibledigitalaudiodeviceorvideodisplay.
2Headphoneconnector
Connectaheadphoneorpoweredspeakerstolistentotheaudiooutput.
3Microphoneconnector
Connectamicrophonetocapturesound.
4USBconnectors
ConnectcompatibleUSBdevices.
5Ethernetconnector
ConnectyourtablettoaLAN(10/100Mbps).
